Product Introduction
The GE MPU50 369B1860G0026 iDPU Module is the intelligent core for demanding automation systems. It provides high-speed control and reliable data processing. This module features a fully redundant architecture for maximum uptime. It easily manages large I/O networks with precision.
Technical Specifications
- Brand & Model: General Electric MPU50 369B1860G0026 iDPU Module
- Processor: Intel® 1.66 GHz 64-bit embedded CPU.
- System Memory: 1GB DDR2 RAM (667/800 MHz).
- Storage: 2GB onboard non-volatile flash memory.
- Control Network: 1Gbps redundant UDH Ethernet connections.
- I/O Network: 1Gbps redundant Ethernet for I/O data.
- Serial I/O Bus: 4 smart, high-speed redundant buses (1Mbps each).
- Peer-to-Peer Link: 1Gbps dedicated dual tracking network.
- Max I/O Capacity: Controls up to 48 Nexus I/O modules.
- Operating System: QNX® real-time operating system (RTOS).
- Scan Cycle: Fastest execution down to 40ms.
- Configuration: Supports up to 999 control pages.
- Time Sync: NTP sync with ±1ms accuracy, 1ms SOE.
- Power Input: Redundant 24V DC supply (15V 3A output).
- Operating Temp: Stable from 0°C to 60°C.
- Environmental: Built for harsh industrial conditions.
- Noise Immunity: High resistance to electrical interference.
Easy Installation Guide
- Mount the module on a standard DIN rail.
- Connect the provided power cord to the redundant 24V DC inputs.
- Always use both power inputs for full system redundancy.
- Use shielded cables for network links in noisy areas.
- Ensure good airflow and stay within the temperature range.
Maintenance & Diagnostics
- The module supports advanced remote diagnostic tools.
- It continuously monitors network and power supply health.
- Detailed system logs enable fast fault finding.
- Hot-swappable design reduces downtime.
- Online firmware updates keep the system current.
Compatibility & Integration
- Core component of the GE MPU50 series.
- Works seamlessly with GE Nexus I/O modules.
- Standard Ethernet allows easy plant network integration.
- The QNX OS ensures stable, deterministic control.
Certifications & Package
- Complies with key industrial standards.
- Package Includes: 1x GE MPU50 iDPU Module, 1x Power Cord, Docs.
- Items ship in protective, industrial packaging.
- Warranty: Full 12-month warranty on parts and workmanship.
Shipping & Delivery
We ship globally with reliable carriers: FedEx, UPS, and DHL. Tracking info is provided after dispatch.
Typical Applications
- Critical process control systems.
- High-speed machine automation lines.
- Redundant safety control systems.
- Distributed I/O and data acquisition.
- Plant-wide supervisory control.
Frequently Asked Questions (FAQ)
- What is this module’s primary role?
- It serves as the main processor in a GE control system, running logic and managing I/O.
- Why choose a redundant design?
- Redundancy eliminates single points of failure. This greatly improves system availability.
- How many I/O modules connect?
- It supports a maximum of 48 Nexus I/O modules in total.
- Is the memory upgradeable?
- No, the 1GB RAM and 2GB flash are fixed and soldered onboard.
- What if one power supply fails?
- The second, redundant power input takes over immediately with no control interruption.
- Is the 40ms cycle time fixed?
- It is the fastest possible cycle. Actual time depends on the program size and complexity.
- Any pro tips for first-time setup?
- Configure network time protocol (NTP) first. Consistent timing is vital for alarms and event sequences.
- How does it perform long-term?
- Exceptionally well. Its robust hardware and real-time OS are designed for continuous 24/7 operation for many years.
