Description
Power Your Precision Control
Meet the GE Nexus MAO50 369B1842G5005. This 8-channel analog output module delivers high-accuracy signals for critical process control. Its robust and redundant design ensures reliable operation in tough industrial environments. Simplify your system integration with this versatile module.
Complete Technical Specifications
- Brand & Model: General Electric MAO50 369B1842G5005 Analog Output Module.
- Series: Part of the reliable GE Nexus I/O family.
- Channel Count: 8 isolated output channels.
- Output Signals: 0(4)-20mA on all channels. Select channels also support 0(1)-5V.
- Load Capacity: 0-1000Ω for current output, min. 500kΩ for voltage output.
- Converter Resolution: 12-bit Digital-to-Analog (D/A) converter per channel.
- Overall Accuracy: Better than ±0.1% of full scale.
- Power Supply: Redundant 24V DC (±10%). Typical consumption under 6.5W.
- Isolation Rating: 250VAC between channels, 500VAC channel-to-ground, 1500VAC system isolation.
- Noise Immunity: Excellent Common Mode Rejection Ratio (CMRR) >120 dB.
- Connectors: DB-9 for communication; pluggable European-style terminal block for wiring.
- Wire Gauge: Accepts up to 2.5mm² (14 AWG) for easy connection.
- Operating Temperature: Stable performance from 0°C to +60°C.
- Humidity Range: 10% to 90% non-condensing.
- Dimensions: 209mm H x 129.5mm W x 51mm D.
Simple Installation & Maintenance
- Mount the MAO50 module on a DIN rail using screws.
- Connect the two redundant 24V DC power wires for safety.
- Use the pluggable terminal block for field wiring. It makes replacement fast.
- The bright LEDs give instant visual health status. No tools needed for basic checks.
- Designed for minimal maintenance in dusty environments.
Compatibility & Certifications
- Designed to work perfectly with GE MPU50 and other GE controllers.
- Communicates via the high-speed 1Mbps Nexus serial bus.
- Complies with CE, FCC, IEC 61326, and other key industrial standards.
- Tested for electromagnetic compatibility (EMC) and electrical noise immunity.
What’s in the Box & Support
- 1 x GE Nexus MAO50 369B1842G5005 Module.
- All necessary documentation for installation.
- Full 12-Month Warranty: We guarantee parts and workmanship for one year.
- Fast Global Shipping: We dispatch via FedEx, UPS, or DHL with tracking.
Expert Frequently Asked Questions
- What systems is the MAO50 module designed for?
- It is built for GE’s Nexus and MPU series control platforms. It is ideal for process loops requiring precise analog control.
- Can I mix current and voltage outputs on one module?
- Yes, the MAO50 369B1842G5005 supports this. You can configure each channel independently in the controller software.
- Why is the 1500VAC system isolation important?
- This high isolation protects the sensitive control system from dangerous voltage spikes or faults in the field wiring, preventing damage.
- How do I know if a channel has failed?
- The module’s fault LED will activate. For detailed channel-level diagnostics, check the status in the GE controller programming software.
- From experience, what is a common setup error?
- Not using the redundant power inputs. Always connect both 24V sources. This simple step prevents unexpected shutdowns if one power line fails.
- Is the 12-bit resolution sufficient for my application?
- For most industrial control applications like valve positioning or speed setpoints, 12-bit resolution provides excellent smooth and precise control.
- Can this module operate in a very dusty plant?
- Yes, its design accounts for particulate contamination. However, for extreme conditions, consider an additional protective enclosure for optimal longevity.
