MTL4549 Dual Isolator: Drive Two Devices with HART Support
The MTL4549 takes two 4-20mA control signals and safely drives devices in hazardous areas. It works with I/P converters, valve positioners, and other loads. It supports HART communication and finds wiring problems.
Technical Specifications
Brand & Model: MTL MTL4549 Dual Isolator
Channels: Two independent channels
Input/Output Signal: 4-20mA with HART
Load Capacity: Up to 800Ω per channel
Output Voltage: 16V at 20mA
Digital Bandwidth: 500Hz to 10kHz
Accuracy: Better than 20μA
Response Time: < 100ms
Power Supply: 20-35V DC
Power Consumption: 70mA at 24V
Fault Detection: Open and short circuit
Operating Temperature: -20°C to +70°C
Simple Connection
Connect your two controller outputs. Connect your field devices like I/P converters. The MTL4549 provides isolation and passes HART signals.
Frequently Asked Questions
Q1: Can I use both channels for different devices?
A1: Yes, each channel works independently with different devices.
Q2: What wiring problems does it detect?
A2: It finds both broken wires (open circuit) and shorted wires.
Q3: Does it work with non-HART devices?
A3: Yes, it works perfectly as a standard 4-20mA isolator for any device.
Q4: What is the advantage of two channels?
A4: It saves space and cost compared to using two single-channel units.
Q5: How much power does it need?
A5: It uses only 70mA at 24V, making it energy efficient.
