Description:
The CC-PDIH01 51405041-175 is a high-voltage digital input module designed for seamless integration into various industrial automation systems. It provides reliable input detection for both 24 VDC and 120 VAC signals. The module is engineered for optimal performance in harsh environments, offering excellent isolation and a wide operating temperature range. This product is ideal for use in control systems, machinery monitoring, and other applications requiring high-speed input signals.
Technical Data:
| Specification | Details |
|---|---|
| Brand | Honeywell |
| Model | CC-PDIH01 51405041-175 |
| Input Voltage | 24 VDC, 120 VAC |
| Input Current | 5 mA (24 VDC), 2 mA (120 VAC) |
| Input Impedance | 4.7 kΩ (24 VDC), 56 kΩ (120 VAC) |
| Max Input Frequency | 10 kHz |
| Isolation Voltage | 1500 VAC |
| Operating Temp | 0 to 60°C (32 to 140°F) |
| Storage Temp | -40 to 85°C (-40 to 185°F) |
| Humidity Range | 5 to 95% non-condensing |
| Dimensions | 45 x 120 x 120 mm (1.77 x 4.72 x 4.72 in) |
| Weight | 0.5 kg (1.1 lb) |
