Description
Precision Temperature Monitoring Expert
The GE Fanuc IC200ALG620 is a 4-channel RTD input module with 16-bit accuracy. Built for industrial systems needing reliable temperature tracking across diverse environments.
Core Specifications
- ????️ Channels: 4 inputs (3/4-wire RTD)
- ???? Sensor Support: Platinum, Copper, Nickel, Nickel/Iron (25Ω to 3000Ω)
- ???? Accuracy: ±0.15% (resistance & temperature at 25°C)
- ⏱️ Speed: 210ms per channel update (60Hz)
Industrial-Grade Features
- ????️ Isolation: 250V AC (input-to-logic) | 1500V AC (input-to-frame)
- ???? Smart Diagnostics: Detects open wires, shorts, over/under-range errors
- ???? Flexibility: Handles 0-500Ω and 0-3000Ω resistance ranges
- ???? LED Status: Green (operational) / Amber (fault) indicators
Where It Shines
- ???? Chemical reactor temperature control
- ???? Industrial oven monitoring
- ❄️ Cold storage facility HVAC systems
Installation Notes
- ⚠️ Lead Resistance: Max 5Ω per wire
- ????️ Temp Limits: 0°C to 60°C operating range
- ???? Power: 125mA @5VDC/3.3VDC (backplane)
Package & Support
- ???? IC200ALG620 module + installation guide
- ???? 12-month defect warranty
- ???? Shipping: FedEx/UPS/DHL – global delivery in 3-5 days
