GE Fanuc IC200MDL744 Discrete Output Module – 32-Point VersaMax Solution
Product Overview
Versatile 32-point negative logic output module for VersaMax systems. Supports 5V/12V/24V DC operation with dual isolated groups. Ideal for high-density output applications requiring sinking capabilities.
Technical Specifications
| Brand | GE Fanuc |
| Series | VersaMax |
| Model | IC200MDL744 (Full Suffix) |
| Output Points | 32 (2 groups × 16 points) |
| Logic Type | Negative (sinking) |
| Voltage Ranges | 5V TTL (4.75-5.25V), 12/24V DC (10.2-30V) |
| Isolation | 250V AC continuous (1500V AC 1min) |
| Response Time | 0.2ms ON / 1ms OFF |
| Backplane Power | 5V DC, 140mA |
Compatibility
Works with: VersaMax PLCs (requires NIU or CPU). Connects to relays, solenoids, indicators. External suppression required for inductive loads.
Installation Steps
- Power down VersaMax rack
- Insert module in compatible slot
- Connect field wiring per terminal diagram
- Add suppression circuits for inductive loads
- Verify FLD PWR and OK LEDs
Package Includes
- IC200MDL744 Module
- Installation manual
- Terminal labels
Shipping Info
Global delivery via FedEx, UPS, DHL. Tracking provided within 24hrs.
FAQ
Internal fuse protection?
No – External circuit protection required
Positive logic support?
No – Negative (sinking) logic only
Minimum load voltage?
4.75V (TTL mode), 10.2V (12/24V mode)
Status indicators?
FLD PWR (field power), OK (backplane power), per-point LEDs
