IC697MDL253 GE Fanuc Series 90-70 Discrete Input Module

Description

GE Fanuc IC697MDL253 24V AC 32-Point Input Module

Product Description

This 24V AC input module from GE Fanuc’s Series 90-70 PLC family offers 32 isolated input points split into 4 groups. Designed for industrial automation, it works with proximity switches, limit switches, and selector switches. No DIP switches needed—configures via software (Windows NT/95/MS-DOS). LED indicators show real-time input status.

Technical Data

• Brand: GE Fanuc (GE Intelligent Platforms)
• Model: IC697MDL253 (Series 90-70)
• Voltage: 24V AC ±10%
• Input Points: 32 (4 isolated groups of 8)
• Input Current: 10 mA (On-State), 2 mA leakage (Off-State)
• Frequency: 47-63 Hz
• Filter: 20-microsecond noise rejection
• Power: AC only (0.30A current draw)
• LED Indicators: Per-point status monitoring

Installation Guide

1. Mount in Series 90-70 PLC rack (mechanical key prevents wrong insertion)
2. Connect AC power (24V) and field devices
3. Configure via GE programming software (Windows-based)

Packaging & Shipping

• Package Includes: IC697MDL253 module, installation manual
• Shipping: FedEx, UPS, or DHL (global delivery)
• Delivery Time: 3-5 business days (express options available)

FAQs

Q: Does it work with DC sensors?
A: No—designed for 24V AC inputs only.

Q: Can I use 2-wire proximity switches?
A: Yes, but 3-wire switches are recommended for lower voltage drop.

Q: Is software included?
A: Programming tools sold separately (e.g., Proficy Machine Edition).
