GE Fanuc IC697MDL340 Output Module: 16-Point AC Control with Isolated Groups
Product Description
The GE Fanuc IC697MDL340 is a 120V AC output module for Series 90-70 PLC systems. It delivers 16 outputs split into 4 isolated groups (4A/group, 2A/point), ideal for controlling inductive loads like motors, solenoids, and contactors. Features LED status indicators, mechanical keying for safe replacement, and fused protection (10A fuse/group). No jumpers/DIP switches needed for configuration.
Technical Data
- Brand: GE Intelligent Platforms/GE Fanuc
- Model: IC697MDL340 (Full Suffix: IC697MDL340-AA)
- Voltage: 120V AC ±15%
- Outputs: 16 (4 isolated groups)
- Current: 2A/point, 4A/group
- Inrush Current: 20A (10x rated)
- Frequency: 47-63 Hz
- Power: AC only
- Indicators: Per-point status + fuse health LEDs
Installation & Compatibility
Installation: Mount in Series 90-70 rack. Mechanical keying prevents incorrect insertion.
Compatible With: Size 4 contactors, motor starters, incandescent/inductive loads, GE 90-70 PLCs.
Application Examples
- Manufacturing: Controls 16 motor starters in packaging lines.
- HVAC Systems: Manages solenoid valves in industrial cooling units.
FAQ
Q: Can it handle high inrush loads?
A: Yes – supports 20A inrush (10x rating) for lamps/inductors.
Q: Replacement precautions?
A: Use mechanical keying to ensure correct module type.
Q: Config software needed?
A: No – operates without jumpers/DIP switches.
