Description
Product at a Glance
- ICS Trusted Communications Interface – Model T8151
- Type: Communications Module for safety systems.
- Delivers reliable data exchange in critical processes.
- Works with T8100 and T8300 I/O slots.
Key Features (Simple View)
- 2 Ethernet ports – 10/100BaseT for fast networks.
- 4 rear serial ports – two RS-232/422/485 + two RS-422/485.
- 1 diagnostic serial port – RS-232 for front panel checks.
- Supports many protocols – Modbus RTU, Modbus TCP, Trusted Peer to Peer, ICS2000, CP2000.
- SOE buffer – holds 4000 events.
- Baud rates – from 1200 to 115200 baud.
Technical Data (Simple Format)
- Power supply – 20 to 32 Vdc, 14 W.
- Backplane supply – 20 to 32 Vdc.
- Power dissipation – 10 W.
- Fusing – not user serviceable.
- Isolation – 50V basic (module to backplane, module to diag port). 250V basic (module to rear serial, to Ethernet, serial to Ethernet, between serial ports, between Ethernet ports).
Environmental & Physical Specs
- Operating temp – 0°C to +60°C (+32°F to +140°F).
- Storage temp – -25°C to +70°C (-13°F to +158°F).
- Humidity – 10% to 95%, non-condensing.
- Height – 266 mm (10.5 in).
- Width – 31 mm (1.2 in).
- Depth – 303 mm (12.0 in).
- Weight – 1.13 kg (2.49 lb).
Certifications
- Ord – general purpose.
- HazLoc – hazardous locations.
- ATEX & IECEx – explosive atmospheres.
Installation in 5 Steps
- 1. Insert module into T8100 or T8300 I/O slot.
- 2. Secure with latches – no tools needed.
- 3. Connect backplane supply (20-32 Vdc).
- 4. Wire rear serial and Ethernet cables.
- 5. Use diagnostic port for first check.
Debugging & Daily Care
- Front diagnostic port shows live data logs.
- Check LEDs: power, fault, link status.
- Update firmware via Ethernet – no special cable.
- Hot-swap allowed under Trusted system.
Compatibility
- Works with ICS Triplex Trusted TMR controllers.
- Talks to Modbus TCP and RTU masters.
- Replaces older T8150 modules directly.
- Fits existing DCS and PLC networks.
Typical Use Cases
- Oil refinery communication links.
- Power station control networks.
- Chemical plant safety systems.
- Water treatment data gathering.
- Mining with hazardous area needs.
Diagnostic Tools
- Self-checks by Trusted OS every cycle.
- LEDs show: Run, Fault, Ethernet Act/Link.
- Loopback test via diagnostic serial port.
- Ping test from dual Ethernet ports.
- Stores last 10 faults with time.
FAQ – 5 Professional Questions
- What is the exact power of T8151?
20-32 Vdc, 14 W input, 10 W dissipation. - Does T8151 work without backplane supply?
No. It needs 20-32 Vdc from the backplane. - Can I use all four serial ports at once?
Yes. Two are RS-232/422/485, two are RS-422/485. - Is the diagnostic port for normal use?
No. It is only for setup and error checking. - What happens above 60°C?
Performance may drop. Keep within 0-60°C range.
Experience-Based Buying Guide
- Buy T8151 if you need SIL‑1 or SIL‑2 communication.
- For high vibration areas, add extra mounting clips.
- Keep one spare diagnostic cable for field fixes.
- Check your zone before ATEX use – Zone 2 gas or Zone 22 dust.
- Firmware V4.0 or newer gives full protocol support.
- Pair with Trusted T8100 chassis for best results.
Selection Guide (What to Pick)
- Need dual Ethernet + 4 serial ports → choose T8151.
- Only need 2 serial ports → consider older T8150.
- Working in cold area (-25°C) → T8151 works fine.
- Require 4000 SOE events → T8151 has built‑in buffer.
- Upgrading from ICS2000 → T8151 supports that protocol.
Packing List
- T8151 Communications Module – 1 unit.
- Quick start card – 1 copy.
- Diagnostic serial cable – 1 piece.
- Warranty card (12 months) – 1 card.
Shipping & Delivery
- Carriers: FedEx, UPS, DHL.
- Worldwide express – 3 to 5 business days.
- Tracking link sent within 24 hours.
- We help with customs documents.
Warranty & Support
- 12 months warranty from invoice date.
- Free technical help via email or phone.
- We send replacement during repair.
- For questions: +86 158 8020 0923 (WhatsApp).
