Product Overview: Heavy-Duty Protective Enclosure
This is the Bently Nevada 31000 Proximity Probe Housing Assembly. It safely houses and protects sensitive 8 mm vibration probes. It is built for tough industrial areas. This housing shields your probe from water, impacts, and harsh conditions. It ensures your monitoring system stays reliable.
Complete Product Breakdown: Model 31000-28-10-00-235-00-02
- Core Product Identity
- Brand: Bently Nevada
- Full Part Number: 31000-28-10-00-235-00-02
- Type: Protective Housing Assembly
- Designed For: 3300 XL 8 mm Proximity Probes
- Key Configuration & Build
- Section A (Probe): 28 = Comes with a certified 3300 XL 8 mm probe.
- Section B (Cable): 10 = Includes 1.0 inch of probe cable within housing.
- Section C (Adapter): 00 = No standoff adapter included.
- Section D (Length): 235 = Provides 23.5 inches of probe penetration depth.
- Section E (Fittings): 00 = Supplied without extra pipe fittings.
- Section F (Thread): 02 = 3/4-14 NPT mounting thread for installation.
- Robust Construction Details
- Main Body: Conductive, glass-reinforced PPS plastic.
- Internal Sleeve & Chain: Durable AISI 304 stainless steel.
- External Hardware: Corrosion-resistant AISI 303 stainless steel screws.
- Seals: Neoprene O-ring between sleeve and housing.
- Installation Torque: Tighten retaining nut to 29.4 N·m (260 in·lb).
- Weight: Approximately 1.2 kg (2.6 lb).
- Environmental & Safety Ratings
- Operating Temperature: -51°C to +105°C.
- Enclosure Protection: NEMA 4X & IP66 rated against water and dust.
- Hazardous Area: Meets CENELEC EN50014 for electrostatic safety.
- Impact Strength: Certified to survive 4 Joule impacts at extreme temperatures.
- Structural Strength: Housing supports over 200 lbs of force.
- Ordering & Service Info
- Shipping: We ship globally via FedEx, UPS, and DHL.
- Warranty: Backed by a 12-month product warranty.
- Support: Contact our engineers on WhatsApp for help.
Frequently Asked Questions (FAQ)
Installation & Use
Q: What is the main purpose of this housing?
A: It protects the expensive 8 mm probe inside from physical damage, water jets, and dust in harsh plant environments.
Q: How do I install the probe into this housing?
A: Insert the probe through the sleeve. Secure it with the internal retaining nut using the specified torque.
Selection & Compatibility
Q: Can I use this housing with a 5 mm or 11 mm probe?
A: No. The 31000-28-… model is specifically designed for 3300 XL 8 mm probes only.
Q: The penetration depth is 23.5 inches. What if I need less?
A: The probe can be positioned at any required depth inside the sleeve up to the maximum.
Expert Application Tip
Q: Where is this housing typically used?
A: Perfect for outdoor turbines, wet compressor stations, or any location where the probe needs extra mechanical and environmental protection.
