GE Fanuc IC693MDL632 High-Voltage Input Module
125VDC industrial input module for Series 90-30 PLCs. Handles 8 high-voltage signals with dual isolated groups. Perfect for heavy machinery monitoring.
Core Advantages
- 125VDC rated voltage (150VDC max)
- Dual isolated input groups (4 points each)
- Positive/Negative logic flexibility
- Visual status LEDs for all inputs
- 1500V safety isolation barrier
Technical Specifications
- Brand: GE Intelligent Platforms
- Full Model: IC693MDL632
- Voltage Range: 0-150VDC
- On Voltage: 90-150VDC
- Off Voltage: 0-30VDC
- Current Draw: 3.1mA (on-state)
- Isolation: 1500V field/logic, 500V between groups
- Response Time: <10ms typical
- Contact Rating: 5W minimum
Installation Guide
Mounts in 5-slot or 10-slot baseplates. Requires separate power for field devices. Connect inputs to dedicated commons. Blue-edged door indicates voltage status.
Compatible Systems
- All Series 90-30 PLC racks
- High-voltage sensors (90-150VDC)
- Industrial limit switches
- Motor control circuits
Package & Support
Includes module and installation guide. Backed by 12-month warranty. Ships worldwide via FedEx, UPS, DHL.
Technical Questions
Q: How are inputs grouped?
A: Two isolated groups of 4 points each
Q: Maximum voltage tolerance?
A: 150VDC absolute maximum
Q: Can I use AC voltage?
A: No, DC only (0-150VDC)
Q: LED indicators?
A: 8 individual LEDs show input status
Q: Power requirements?
A: Field devices require separate power supply
