M12 Axial Connector Cable | Leuze K-D M12A-4P-2m-PVC

Description

Product Overview: Leuze K-D M12A-4P-2m-PVC

This is a high-quality industrial sensor connection cable from Leuze. It provides a reliable link for your devices in tough environments. The design is robust and ensures stable signal transmission.

Key Features & Benefits

• Extreme Durability: Features a tough PVC outer jacket that resists oils, coolants, and abrasion for long life.
• Vibration-Proof Lock: The screw-locking mechanism (0.6 Nm torque) ensures a secure connection that won’t shake loose.
• Universal Compatibility: Standard 4-pin M12 axial connector works with a vast range of sensors and industrial devices.
• Flexible Application: Suitable for both fixed cabinet wiring and moving applications in cable carriers.
• Safe & Reliable: Meets Insulation Category I (IEC 60664-1) for safe operation up to 250V AC/DC.

Decoding The Model Number

• K-D – K-D Series Connection Cable
  • M12A – M12 Connector, Axial (Straight) Style
    • 4P – Number of Pins: 4
      • 2m – Cable Length: 2 Meters
        • PVC – Cable Jacket Material: Polyvinyl Chloride

Complete Technical Specifications

• Brand: Leuze
• Model: K-D M12A-4P-2m-PVC
• Series: K-D Connection Cable
• Connector Type: M12, Axial (Straight)
• Pin Count: 4 pins
• Cable Length: 2.0 meters (78.7 inches)
• Jacket Material: PVC, Black
• Max Operating Voltage: 250V AC/DC
• Max Current per Pin: 4 Amps
• Conductor Size: 0.34 mm² (22 AWG)
• Outer Diameter: Approx. 5.2 mm
• Min Bending Radius: 10 x cable diameter (52 mm for flexible use)
• Locking Type: Metal screw-lock, nickel-plated
• Recommended Torque: 0.6 Nm
• Insulation Rating: Category I (IEC 60664-1)
• Operating Temp (Fixed): -30°C to +70°C
• Operating Temp (Flex): -5°C to +70°C
• Ingress Protection: IP67 when mated
• Shielding: Yes, for EMI/RFI protection
• Contact Material: Gold-plated for low resistance
• Flame Rating: Complies with industrial flame-retardant standards

Shipping & Warranty Information

• Global Shipping: We ship worldwide via FedEx, UPS, and DHL for fast, trackable delivery.
• Quality Guarantee: This product is covered by a 12-month warranty against defects in materials and workmanship.

Frequently Asked Questions (FAQ)

Q: Is this cable suitable for use in wet conditions?

A: Yes, when the connectors are fully mated and screwed together, the assembly achieves an IP67 rating, making it dust-tight and capable of withstanding temporary immersion in water.

Q: Can I cut and re-terminate this cable to a custom length?

A: This is a factory-molded cable. For reliability, we do not recommend cutting and re-terminating it. Please order the standard length you need.

Q: What is the difference between ‘axial’ and ’90-degree’ M12 connectors?

A: Axial (or straight) connectors come out in-line with the cable. 90-degree connectors bend at a right angle, which can be useful in tight spaces to save room.

Q: From a maintenance standpoint, what’s a common issue with these cables?

A: The most common issue is not tightening the screw lock enough, leading to intermittent connection faults from vibration. A firm hand-tightening is usually sufficient.

Q: Does the 4-pin configuration support both power and signal?

A: Yes, a standard 4-pin M12 connector is very versatile. It is commonly used to provide DC power (e.g., 24V on two pins) and carry a switched signal back on the other two pins for sensors.
