The Panasonic MCDLT35SF is a cutting-edge multifunctional drive designed to offer position, speed, and torque control in one compact unit. Part of the MINAS A6SF Series, this versatile drive provides advanced performance and precision control for industrial automation applications. With a response frequency of 3.2 kHz and a 23-bit absolute encoder, the MCDLT35SF delivers high-resolution feedback, making it ideal for high-performance tasks. The drive also integrates essential safety functions for secure and efficient operation.
Technical Data
- Brand: Panasonic
- Model: MCDLT35SF
- Series: MINAS A6SF Series
- Control Type: Position, speed, torque control, fully closed-loop control
- Response Frequency: 3.2 kHz
- Safety Features: Integrated safety functions
- Power Supply: Single-phase/three-phase, 200V +/- 15%, 50/60 Hz
- Encoder Feedback: 23-bit absolute encoder (8388608 resolution)
- Dimensions (W x H x D): 65 mm x 150 mm x 170 mm
- Weight: 1.6 kg
- Communication Functions: USB, RS232, RS485, Modbus-RTU
- I/O Functions: Universal input/output signals, analog inputs, pulse outputs
- Regenerative Resistor: Built-in with external connection capability
- Feedback Options: Encoder or external displacement sensor feedback
I/O Connectors
- 10 universal input signals
- 6 universal output signals
- 3 analog input signals (16-bit A/D and 12-bit A/D)
- 2 analog output signals
- 2 pulse signal inputs
- 4 pulse signal outputs (including long line driver output)
