MHMF012L1U2M Panasonic MINAS A6 MHMF Series AC Servo Motor

Description

MHMF012L1U2M Panasonic MINAS A6 MHMF Series AC Servo Motor

MHMF012L1U2M is a Panasonic AC servo motor from the MINAS A6 MHMF series.
It is a high inertia motor designed for stable and precise motion control.
The motor delivers smooth speed control and reliable torque output.
It is widely used in automation machines, robotics, and industrial production equipment.

Main Technical Overview

• Brand: Panasonic
• Model: MHMF012L1U2M
• Motor type: AC servo motor
• Series: MINAS A6 MHMF
• Motor structure: High inertia
• Rated power: 100 W
• Power supply capacity: 0.5 kVA
• Voltage rating: 200 V
• Rated current: 1.1 A RMS
• Motor weight: 0.42 kg

Motion Performance

• Rated speed: 3000 r/min
• Maximum speed: 6500 r/min
• Rated torque: 0.32 N·m
• Stall torque: 0.33 N·m
• Peak torque: 1.11 N·m
• Maximum current: 5.5 A
• Rotor inertia: 0.071 × 10⁻⁴ kg·m²
• Recommended load inertia ratio: up to 30 times

Mechanical Design

• Shaft type: keyed shaft with thread
• Brake: none
• Seal design: oil seal included
• Compact industrial motor structure
• Designed for high durability

Brake and Energy Handling

• Unlimited regenerative brake frequency
• Supports external regenerative resistor
• Compatible resistor model: DV0P4281
• Stable deceleration performance
• Suitable for frequent start-stop operations

Typical Equipment Compatibility

• Industrial servo drive systems
• Panasonic MINAS A6 servo drivers
• Automatic assembly machines
• Robotic arms and manipulators
• CNC equipment
• High precision motion platforms

Application Scenarios

• Packaging machinery
• Semiconductor equipment
• Labeling machines
• Electronic assembly production lines
• Pick and place robots
• Automated inspection machines

Diagnostic Capability

• Stable feedback response for precise control
• Supports servo system monitoring
• Fast fault response with servo driver alarms
• Helps detect load imbalance
• Improves machine stability and maintenance efficiency

Manager’s Insight

• This motor is designed for stable motion systems.
• The high inertia design improves speed stability.
• It is very useful in machines with sudden load change.
• The compact size helps reduce machine space.
• It works best with Panasonic MINAS A6 servo drives.

Warranty and Delivery

• 12-month warranty
• Original industrial automation product
• 24–48 hour fast dispatch
• Secure export packaging
• Worldwide shipping via FedEx, UPS, DHL

Professional FAQ

• How do I choose the correct servo motor size?
• Check the required torque, load inertia, and speed of your machine.
  Choose a motor that provides enough torque margin for safe operation.
• Is this motor suitable for high speed machines?
• Yes. The maximum speed reaches 6500 r/min.
  It fits machines that need quick motion response.
• What should I check before installing the servo motor?
• Check shaft alignment, mounting strength, and cable connection.
  Good installation improves motor life.
• When should an external regenerative resistor be used?
• If the machine stops frequently or has heavy loads.
  The resistor helps absorb excess energy during braking.
• How can users avoid servo motor overheating?
• Make sure the load inertia ratio is within limits.
  Also keep enough ventilation around the motor.
