MTL Dual-Channel Signal Isolator | Fast Delivery MTL5049

Description

MTL5049: Twin-Channel Hazardous Area Guardian

Drive two explosion-zone devices from safety! The MTL5049 barrier takes dual 4-20mA signals and powers hazardous-area loads. Double protection in one unit. Zone 0 certified.

????️ Dual Defense System

• Controls 2 devices in explosive areas
• Ultra-fast 250μs signal transfer
• Massive 550Ω load capacity
• Super-stable: <1μA/°C drift

⚙️ Performance Metrics

• Input Range: 0-24mA (safe area)
• Output Range: 4-20mA (550Ω max)
• Accuracy: ±20μA at 20°C
• Response: 250μs settling time
• Ripple: <40μA peak-peak
• Voltage Drop: <4V @ 20mA
• Power: 20-35V DC (50-75mA)
• Isolation: 1500V AC barrier
• Temp Range: -40°C to +80°C

???? Terminal Quick-Connect

• 1,2: Channel 1 Output (-/+)
• 4,5: Channel 2 Output (-/+)
• 8,9: Channel 2 Input (-/+)
• 11,12: Channel 1 Input (-/+)
• 13,14: Power Supply (-/+)

✅ Risk-Free Ownership

• 12-month worry-free warranty
• Express shipping: Fedex, UPS, DHL
• Power-on LED health check

???? Pro Knowledge

Q1: How many devices can one MTL5049 run?
A: Two! Controls dual hazardous-area loads simultaneously.

Q2: What’s the max cable resistance?
A: Supports up to 550Ω load resistance.

Q3: Does it work in freezing conditions?
A: Yes! Operates from -40°C to +80°C.

Q4: How much voltage does it need?
A: Only 20-35V DC. Sips 50-75mA power.

Q5: What safety approvals apply?
A: Zone 0, IIC (T4-T6) and Division 1 Group A.
