MTL5012 Safety Switch: Hazardous Area Control for Solid-State Outputs
Safe Control from Dangerous Locations
The MTL5012 lets you safely operate equipment using switches in explosive areas. Works with proximity detectors and offers line fault detection. Perfect for industrial safety systems.
Key Features
- NAMUR/DIN 19234 compatible – works with standard sensors
- Line fault detection – protects your system
- Output phase reversal – flexible configuration
- Fast response – up to 5kHz operation
- Three status LEDs – easy monitoring
Technical Specifications
| Model | MTL5012 Safety Interface |
| Input Standard | NAMUR/DIN 19234 |
| Output Current | 50mA maximum |
| Response Speed | DC to 5kHz |
| Sensor Voltage | 7-9V through 1kΩ |
| Power Consumption | 28-32mA (20-35V) |
Wiring Connections
1: Input (-ve)
2: Input (+ve)
10-11: Output (-ve)
12: Output (+ve)
13: Power (-ve)
14: Power (+ve)
Safety Approvals
Certified for:
• Zone 0, IIC, T6 hazardous areas
• Division 1, Group A locations
LED Indicators
Green: Power ON
Yellow: Output active
Red: Line fault detected
Expert Answers
Q: What sensors work with MTL5012?
A: Any NAMUR/DIN 19234 standard proximity detectors.
Q: How does line fault detection work?
A: Detects open circuits (<50µA) and short circuits (<100Ω).
Q: Can I reverse the output logic?
A: Yes, output phase reversal is user-selectable.
Q: What’s the maximum output current?
A: 50mA for connected solid-state devices.
Q: How fast can it switch?
A: Up to 5,000 times per second.
Package Contents
• MTL5012 interface unit
• Installation guide
• Safety documentation
