Description
MTL4032: High-Speed Pulse Interface for Hazardous Areas
The MTL4032 safely transfers pulse signals from switches, sensors, and transmitters in explosive areas to your control system. It handles high-speed signals up to 50kHz with fast response times, making it ideal for counting and speed measurement applications.
Technical Specifications
- Brand: MTL
- Model: MTL4032
- Channels: 1 (fully floating)
- Supported Sensors: Switches, proximity detectors (NAMUR), 2/3-wire voltage/pulse transmitters
- Max Frequency: 50kHz
- Min Pulse Width: 10μs (high and low)
- Proximity Detector Voltage: 7.0-9.0V DC
- Current Pulse Supply: 16.5V DC @ 20mA
- Voltage Pulse Settings: 3V, 6V, or 12V (selectable)
- Output Current: 50mA max
- Power Supply: 20-35V DC
- Current Consumption: 65mA @ 24V DC
- Isolation: 250V AC
- LED Indicators: Power (Green), Input (Amber)
Frequently Asked Questions
- Q1: What types of pulse signals can it handle?
A1: It works with switch contacts, proximity sensors (NAMUR), and 2- or 3-wire voltage/current pulse transmitters. - Q2: How fast can it process signals?
A2: It can handle frequencies up to 50kHz with pulse widths as short as 10 microseconds. - Q3: Can I adjust the switching threshold?
A3: Yes, for voltage pulse inputs, you can select 3V, 6V, or 12V switching points. - Q4: What is the maximum output current?
A4: The output can handle up to 50mA in the on-state. - Q5: Does it work with NAMUR sensors?
A5: Yes, it is specifically designed to work with NAMUR/DIN 19234 proximity detectors.
Safety Certification
Approved for Zone 0, IIC, T4-T6 and Division 1, Group A hazardous locations.
Package Contents
One MTL4032 High-Speed Pulse Interface module.
Warranty
Your purchase includes a 12-month warranty.
Shipping
We ship worldwide via FedEx, UPS, and DHL for reliable delivery.
