Description

MTL5044: Super-Safe Signal Booster for Hazardous Zones

Power two 4-20mA sensors in explosive areas! The MTL5044 safety barrier feeds dangerous-zone transmitters and copies their signals to two safe-area circuits. No signal mix-ups. Zone 0 certified.

⚡ Key Superpowers

• Feeds 2 transmitters in explosive areas
• Clones signals to 2 safe-zone circuits
• Instant response: 250μs ready
• Ultra-precise: ±5μA typical error

???? Tech Specs

• Safe Output: 4-24mA (0-550Ω load)
• Danger Input: 0-24mA (16.5V@20mA)
• Accuracy: Better than 20μA
• Speed: 250μs response
• Ripple: <125μA p-p
• Power: 20-35V DC (80-130mA)
• Temp Range: -40°C to +85°C
• Isolation: 1500V AC tested
• Humidity: 0-95% non-condensing

???? Wire It Right

Terminal Guide:

• 1,2: Channel 1 Input (-/+)
• 4,5: Channel 2 Input (-/+)
• 8,9: Channel 2 Output (-/+)
• 11,12: Channel 1 Output (-/+)
• 13,14: Power (-/+)

???? Peace of Mind Package

• 12-month full warranty
• Fast global shipping: Fedex, UPS, DHL
• Green power LED for easy checks

❓ Hot Questions

Q1: What explosions zones fit the MTL5044?
A: Zone 0, IIC gas groups (T4-T6) and Division 1 Group A.

Q2: Can it handle signal overloads?
A: Yes! Accepts 0-24mA inputs safely.

Q3: How hot can it run?
A: Works from -40°C to +85°C storage.

Q4: Is calibration needed?
A: No! Stable <1μA/°C temperature drift.

Q5: What power connections work?
A: 20-35V DC. Uses under 1.5W power.
