Description
Overview
The Bently Nevada 330103-00-10-05-01-00 proximity probe provides precise radial vibration monitoring for compact industrial machinery. Featuring a 100 mm stainless steel case, 0.5 m cable, and ClickLoc™ connector with integrated protector, this 8 mm probe operates in extreme temperatures (-52°C to +218°C) while maintaining signal integrity.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330103-00-10-05-01-00 |
| Suffix Code | 00: 0 mm unthreaded 10: 100 mm case 05: 0.5 m cable 01: ClickLoc™ + protector 00: No certifications |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Case Material | AISI 303/304 Stainless Steel |
| Thread Engagement | M10×1 (15 mm max) |
| Linear Range | 0.25–2.3 mm (10–90 mils) / -1 to -17 Vdc |
| DC Resistance (RPROBE) | 7.45 Ω ±0.5 @0.5 m |
| Temperature Range | Standard: -52°C to +177°C Extended: -52°C to +218°C (tip), -51°C to +260°C (cable) |
| Humidity Tolerance | <3% ASF change @93% RH (IEC 68-2-3, 56 days) |
| Shielding | 3-conductor shielded triad cable |
Contact Information
For custom pressure testing or hazardous area certifications:
Email: sales@ubestplc.com
