Allen-Bradley 1746-NO4V: 4-Channel Analog Output Module

Precision Voltage Output Control

The Allen-Bradley 1746-NO4V delivers four analog voltage outputs for your SLC 500 system. It generates precise -10 to +10V DC signals for control devices. This 1746-NO4V module offers fast response and high resolution. It fits in one slot and works with all SLC 500 controllers.

Key Technical Specifications

Brand: Allen-Bradley
Model: 1746-NO4V
Type: 4-Channel Analog Output
Output Range: -10 to +10V DC
Resolution: 14-bit
Update Time: 512 µs (all channels)
Step Response: 2.5 ms (95%)
Max Load Current: 10 mA per channel
Load Reactance: 1 µF maximum
Isolation: 500V DC (field to backplane)
Backplane Power: 5V DC, 55 mA / 24V DC, 145 mA
Accuracy Drift: ±54 ppm/°C
Operating Temp: 0 to 60°C (32 to 140°F)
Wire Size: 14 AWG maximum
Terminals: 2 wires per terminal max
Data Format: 16-bit two’s complement
