Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330104-00-04-50-02-05)
Description
The 330104-00-04-50-02-05 is a hazardous area-certified proximity probe for long-range vibration monitoring in explosive environments. Featuring a 5.0-meter armored cable, 40 mm compact case, and M10 x 1 thread, it is exclusively for integration with 5-meter Proximitor sensors. Certified for CSA, ATEX, and IECEx standards, it delivers reliable performance in Zone 1/21 hazardous areas.
Technical Specifications
| Suffix Code | Parameter | Value |
|---|---|---|
| AA: 00 | Unthreaded Length | 0 mm (fully threaded) |
| BB: 04 | Case Length | 40 mm (1.57 in) |
| CC: 50 | Cable Length | 5.0 m (16.4 ft) |
| DD: 02 | Connector Type | Miniature ClickLoc™ (coaxial) |
| EE: 05 | Certifications | CSA/ATEX/IECEx (Zone 1/21) |
| Electrical Properties | ||
| Input Voltage | -17.5 Vdc to -26 Vdc (Barrier: -23 Vdc min) | |
| Probe Resistance | 8.73 Ω ±0.50 @ 5.0 m | |
| Output Impedance | 50 Ω ±5% | |
| Mechanical Properties | ||
| Tip Material | PPS (V-0 Flame Retardant) | |
| Case Material | AISI 304 Stainless Steel | |
| Sealing | Viton® O-ring (-40°C to +204°C) | |
Installation Notes
- ⚠️ Use exclusively with 5-meter Proximitor sensors for API 670 compliance.
- ⚠️ Maintain input voltage ≥-23.5 Vdc to ensure 0.25–2.3 mm linear range.
- ⚠️ Set gap to 1.27 mm (50 mils) on AISI 4140 steel targets.
- ⚠️ Torque M10 threads to 10 N·m (7.37 ft·lb) with anti-seize compound.
