Description
Description
The Bently Nevada 330130-045-03-00 is a high-performance armored extension cable designed for critical industrial monitoring systems. Featuring 4.5 meters (14.8 feet) of stainless steel armored cable with an integrated connector protector, this cable combines mechanical durability with precise signal transmission. Engineered with patented CableLoc technology, it ensures 330 N (75 lbf) pull strength, IP67 protection, and compatibility with 3300 XL probes for vibration and position monitoring in harsh environments.
Technical Data
| Parameter | Specification |
|---|---|
| Brand | Bently Nevada |
| Model | 330130-045-03-00 |
| Suffix Breakdown | -045 (4.5 m cable),
-03 (armored cable + connector protector), -00 (no approvals) |
| Product Type | Armored Extension Cable with Connector Protector |
| Cable Length | 4.5 meters (14.8 feet) |
| DC Resistance (RCORE) | 0.99 ± 0.15 Ω (center-to-center conductor) |
| DC Resistance (RJACKET) | 0.30 ± 0.06 Ω (outer-to-outer conductor) |
| Capacitance | 69.9 pF/m (21.3 pF/ft) |
| Signal Propagation Speed | 0.85c (85% speed of light, typical for coaxial design) |
| Return Loss | >25 dB (1 MHz–10 MHz) |
| Phase Matching Tolerance | ±2° across full operating temperature range |
Contact Information
For pricing or customization, email sales@ubestplc.com
Check official datasheet for more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
