Bently Nevada 3300 XL 8mm Proximity Probe – Compact Industrial Monitoring
Product Description
High-precision 8mm vibration probe with 30mm compact case for space-constrained installations. Features M10x1 threading, chemical-resistant PPS tip, and stainless steel body. Viton® O-ring provides pressure sealing for reliable operation in harsh environments.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 8mm Proximity Probe
- Full Product No.: 330103-00-03-05-02-CN
- Measuring Range: 2.0 mm (80 mils)
- Linear Range: 0.25-2.3 mm (10-90 mils)
- Output Signal: -1 to -17Vdc
- Optimal Gap Setting: 1.27mm (50 mils)
- Cable Length: 0.5 meter (1.6 ft)
- Case Length: 30mm compact design
- Temp Range: -52°C to +177°C
Installation Guide
- Max thread engagement: 15mm
- Use shielded triad cable (0.2-1.5mm²)
- Max wiring distance: 305 meters
- Avoid installation below -34°C to protect seals
Compatibility
Works with all 3300 XL Proximitor Sensors. Supports intrinsic safety barriers (drawing 141092) and nonincendive circuits (drawing 140979).
Certifications
- Country Specific Approval (CN)
- Class I, Zone 0: AEx/Ex ia IIC T5-T1
- IEC 68 2 3 humidity certified
- Hazardous location certified
Package & Warranty
- 1x 8mm Probe with ClickLoc connector
- 12-month manufacturer warranty
- Worldwide shipping: FedEx, UPS, DHL
Industrial Applications
Designed for turbines, motors, and gearboxes in oil/gas, power generation, and heavy manufacturing where space is limited.
FAQ
Q: What does “CN” suffix mean?
A: Country-specific certification for target markets
Q: Pressure rating?
A: Viton® sealed – contact for custom pressure testing
Q: Minimum temperature?
A: -52°C operational but avoid below -34°C during installation
