Description
Bently Nevada 3300 XL 8 mm Proximity Probe
Engineered for precision machinery monitoring in extreme conditions, 330103-00-04-10-01-00 delivers reliable performance with stainless steel construction and hazardous-area certifications.
Key Specifications
- Manufacturer: Bently Nevada
- Model: 3300 XL 8 mm Probe (M10x1 Thread)
- Part Number: 330103-00-04-10-01-00
- Case Length: 40 mm (04 Option)
- Connector Type: ClickLoc with Protector (01 Option)
Performance Details
- Linear Detection Range: 0.25–2.3 mm (-1 to -17 Vdc)
- Optimal Vibration Gap: 1.27 mm @ -9 Vdc
- Cable Resistance: 7.59 Ω ±0.5 (1.0 m length)
- Max Cable Run: 305 m (shielded triad)
- Weight: 323 g/m (11.4 oz/ft)
Environmental Ratings
- Operating Temp:
– Probe Tip: -52°C to +218°C
– Cable/Connector: -51°C to +260°C
- Humidity Stability: <3% ASF shift @ 93% RH (56 days)
- Pressure Seal: Viton® O-ring (custom testing available)
Certifications & Compliance
- ATEX/IECEx:
– Zone 0: AEx/Ex ia IIC T1-T5
– Zone 2: AEx/Ex ec IIB T1-T4
- Class I Div 2 Groups A-D compliant
Package Includes
- Probe assembly (1.0 m cable)
- ClickLoc connector with protector
- Installation guidelines
Note: Avoid sustained exposure below -34°C to preserve seal integrity. For custom configurations or technical support, contact sales@ubestplc.com.
