Description
Product Description
1783-BMS20CGN is a managed industrial Ethernet switch from Allen-Bradley.
It belongs to the Stratix switch family.
The device supports high-speed data flow.
It improves network stability.
It reduces downtime in automation systems.
The switch supports DLR, NAT, and CIP Sync.
It ensures precise time alignment.
It fits control-level and device-level networks.
The design focuses on reliability and security.
Technical Specifications
- Brand: Allen-Bradley
- Series: Stratix
- Model: 1783-BMS20CGN
- Device Type: Managed Ethernet Switch
- Ethernet Copper Ports: 16 Fast Ethernet ports
- SFP Ports: 2 Fast Ethernet SFP slots
- Combo Ports: 2 Gigabit Ethernet copper or fiber
- Switching Capacity: Up to 48 Gbps
- Forwarding Rate: Up to 35.7 Mpps
- MAC Address Table: 16,000 entries
- Firmware: Full feature version
- Power Consumption: Up to 30 W
Core Network Functions
- IEEE 1588 PTP for accurate time stamping.
- CIP Sync for motion coordination.
- NAT for IP address flexibility.
- DLR for fast fault recovery.
- Managed diagnostics for easier troubleshooting.
Performance Characteristics
- Data accuracy improves deterministic traffic.
- Low latency supports real-time control.
- High noise immunity protects signals.
- Stable operation in industrial environments.
Installation Guide
- Mount on DIN rail or control panel.
- Connect power before network cables.
- Label ports for easier maintenance.
- Verify grounding for best performance.
Commissioning and Maintenance
- Configure using Rockwell tools.
- Monitor ports through managed interface.
- Firmware upgrades improve security.
- Minimal routine maintenance required.
Compatibility
- Works with Allen-Bradley PLC systems.
- Supports EtherNet/IP devices.
- Integrates with industrial automation networks.
Certifications
- Designed to meet industrial Ethernet standards.
- Complies with industrial safety requirements.
Packaging List
- 1 × 1783-BMS20CGN Ethernet switch
- Factory inspection label
- Protective industrial packaging
Warranty and Logistics
- Warranty: 12 months
- Shipping: FedEx, UPS, DHL
- Secure export-grade packaging
Typical Applications
- Manufacturing automation lines
- Process control systems
- Motion control networks
- Energy and infrastructure systems
Diagnostics and Monitoring
- Real-time port status monitoring
- Fault detection through managed tools
- Fast isolation of network issues
FAQ
- Is this switch suitable for real-time control?
- Yes. It supports CIP Sync and PTP timing.
- Does it support network redundancy?
- Yes. DLR ensures fast recovery.
- Is configuration complex?
- No. Rockwell tools simplify setup.
- Can it handle network expansion?
- Yes. High MAC capacity supports growth.
- How to choose the right Stratix switch?
- Check port count, redundancy needs, and bandwidth.
