Rockwell Automation 1783-BMS20CGP Stratix Industrial Managed Switch

Description

Product Description

Allen-Bradley 1783-BMS20CGP is a managed industrial Ethernet switch from the Stratix series.
It delivers stable data flow in harsh automation environments.
The device supports DLR and CIP Sync for real-time control.
Compact DIN-rail mounting saves cabinet space.
It fits critical networks where uptime matters.

Core Highlights

• Brand: Allen-Bradley by Rockwell Automation
• Model: 1783-BMS20CGP
• Product Type: Managed Industrial Ethernet Switch
• Network Resilience: Device Level Ring supported
• Time Sync: CIP Sync compliant with IEEE 1588
• Installation: DIN rail, fast and secure

Technical Specifications

• Ethernet Ports: 16 × 10/100 Mbps RJ45
• Combo Ports: 2 × RJ45 or Mini-GBIC
• Gigabit Support: 2 combo ports up to 1000 Mbps
• Power Input: 12–48 V DC
• Power Draw: 21 W at 24 V DC, 40 °C
• Maximum Consumption: 30 W
• Alarm Relay Rating: 1 A at 30 V DC
• Alarm Relay Rating: 0.5 A at 48 V DC

Environmental and Reliability Data

• Operating Temperature: −40 °C to +60 °C
• Protection Level: IP30
• Humidity: 5% to 95%, non-condensing
• Shock Resistance: 30 g during operation
• Vibration Resistance: 2 g from 10 to 500 Hz
• EMI Immunity: Designed for industrial noise environments

Mechanical and Wiring Details

• Dimensions: 12.7 × 12.95 × 13.58 cm
• Weight: Approx. 2.04 kg
• Ground Wire: Minimum 4 mm² stranded copper
• Power Wire: 0.5 mm² recommended
• Terminal Torque: 0.23 Nm for power and alarm

Installation Guide

• Mount the unit on a standard top-hat DIN rail.
• Ensure proper grounding before power connection.
• Use shielded Ethernet cables in noisy areas.
• Allow airflow around the enclosure.

Commissioning and Maintenance

• Web-based management simplifies setup.
• Supports network diagnostics and port status checks.
• LED indicators help quick fault location.
• No routine calibration required.

Compatibility Information

• Optimized for Allen-Bradley automation systems.
• Works with standard Ethernet/IP devices.
• Supports fiber or copper uplinks via combo ports.

Certifications and Compliance

• Designed to meet industrial Ethernet standards.
• Complies with relevant safety and EMC norms.

Typical Applications

• Manufacturing production lines
• Process automation networks
• Machine-level control systems
• Industrial data aggregation

Diagnostic Capabilities

• Ring fault detection with DLR
• Real-time time synchronization monitoring
• Alarm relay for network events

Package Contents

• 1 × 1783-BMS20CGP Ethernet switch
• Quick reference guide
• Factory inspection label

Warranty and Shipping

• Warranty: 12 months
• Shipping: FedEx, UPS, or DHL
• Professional export packaging included

FAQ

• Can this switch run in hot environments?
• Yes. It operates reliably up to 60 °C.
• Is this model suitable for ring networks?
• Yes. It fully supports Device Level Ring.
• Does it need special software?
• No. Standard web browsers handle configuration.
• How do I choose between copper and fiber?
• Use fiber for long distance or high EMI areas.
