Schneider Electric 140DRA84000 Modicon Quantum Relay Output Module

Description

Schneider Electric 140DRA84000 Relay Output Module

The 140DRA84000 is a relay output module for Modicon Quantum. It has 16 outputs. This module works with many load types. It is very strong and lasts a long time. Download the full guide for more details: Download Manual Here.

Key Features

• Brand: Schneider Electric
• Model: 140DRA84000
• 16 relay outputs (Normally Open contacts)
• Works with 20-250V AC and 5-150V DC
• Handles up to 2 Amps per output
• Very long life: 10 million mechanical cycles
• Good isolation: 1780 Vrms between channels and bus

Technical Details

• Response time: 10ms on, 20ms off
• Needs 50 mA minimum load to work well
• Power use: 1100 mA from the baseplate
• Works from 0°C to 60°C (32°F to 140°F)
• Internal protection against voltage spikes
• LED lights show the status of each output

Shipping & Support

• Item comes in its own box
• Size: 12.28″ x 6.42″ x 1.77″
• Weight: 19.2 oz (545 g)
• We ship via FedEx, UPS, and DHL
• 12-month product warranty included

Need help? Contact our support team. Inquiry? Contact: +86 158 8020 0923 on WhatsApp.

Common Questions (FAQ)

• What can I connect to this module?
  You can connect lights, small motors, solenoids, and heaters.
• How long will the relays last?
  They can switch over 10 million times with no load. With a 2A load, they last 100,000 cycles.
• Do I need extra protection parts?
  The module has some protection inside. For heavy motors, you might need more.
• Can I mix AC and DC loads?
  Yes. Different outputs can control AC and DC at the same time.
• What is the minimum load?
  You need at least 50 mA for the contacts to work properly.
