Description
Modicon M340 Network Module: Advanced 4-Port Ethernet Connectivity
The BMXNOC0401 module provides powerful networking for Modicon M340 systems. This advanced Ethernet module features four RJ45 ports and supports multiple industrial protocols. Get complete setup instructions for your BMXNOC0401 by downloading our detailed manual.
- Step-by-step installation guide
- Network configuration examples
- Troubleshooting tips and solutions
- Safety guidelines and specifications
Key Features and Capabilities
- Brand & Model: Schneider Electric BMXNOC0401
- Product Series: Modicon M340 Automation Platform
- Network Ports: 4 x RJ45 Ethernet 10/100 Mbit/s
- Built-in Switch: Embedded 4-port industrial switch
- Protocol Support: EtherNet/IP and Modbus TCP
- Advanced Features: RSTP support and port mirroring
- Web Services: Standard configurable web server
Technical Specifications
- Power Consumption: 555 mA at 3.3V DC
- Operating Temperature: 32°F to 140°F (0°C to 60°C)
- Humidity Range: 10% to 95% non-condensing
- Protection Rating: IP20 for industrial environments
- Product Weight: 0.4 lb (0.2 kg) compact design
- LED Indicators: 5 status lights for easy monitoring
- Hazardous Locations: Approved for Class I Division 2 areas
Packaging and Delivery Information
- Unit Package: 1 network module per box
- Package Dimensions: 4.72 x 4.33 x 2.17 inches
- Package Weight: 7.76 ounces (220 grams)
- Bulk Package: 15 modules per shipping case
- Case Dimensions: 15.75 x 11.81 x 5.91 inches
- Case Weight: 8.06 pounds (3.656 kg)
- Shipping Methods: FedEx, UPS, DHL express service
- Warranty Period: 12-month quality guarantee
Professional FAQ Section
How many devices can connect to this module?
The built-in 4-port switch allows direct connection of multiple devices without extra hardware.
What industrial protocols does it support?
It supports both EtherNet/IP and Modbus TCP for flexible integration with various systems.
Can it operate in harsh environments?
Yes, it works in temperatures from 32°F to 140°F and is approved for hazardous locations.
What is the power requirement?
The module uses 555 mA at 3.3V DC from the main rack power supply.
Does it include network redundancy features?
Yes, it supports RSTP (Rapid Spanning Tree Protocol) for network reliability.
