Schneider Electric Modicon Quantum 140NOA62200 Interbus Master Module

Description

Schneider Electric 140NOA62200 Interbus Master Module

The 140NOA62200 is a Generation 4 Interbus master for Modicon Quantum systems. This advanced module provides high-speed industrial network communication. It supports PCP V2.0 profile for standard automation applications. Download the technical manual: Download Interbus Manual.

Communication Specifications

• Brand: Schneider Electric
• Model: 140NOA62200
• Network Type: Interbus Generation 4 master
• Communication Speed: 500 kbit/s RS485
• Protocol: Interbus DIN 66020 standard
• Cable Type: Twisted pair, 20m maximum distance
• Software: Works with Concept and ProWORX 32

Technical Features

• Memory: 128kB + 256kB firmware, 256kB data RAM
• Power Use: 800mA from Quantum baseplate
• Heat Output: 4W maximum power dissipation
• LED Indicators: 12 status lights for diagnostics
• Connectors: Two SUB-D 9-pin ports
• Compatibility: Works with 140CPU11303 and others

Installation & Operation

• Rack Type: Local Quantum rack installation
• Temperature: 0°C to 60°C operating range
• Weight: 0.9 kg (2.0 lb) module weight
• Certifications: CSA, UL safety standards
• ESD Protection: 4kV contact, 8kV air discharge
• Origin: Manufactured in Germany

Need configuration help? Contact: +86 158 8020 0923 for technical support.

Shipping & Support

• Shipping: FedEx, UPS, DHL express available
• Warranty: 12-month quality guarantee
• Returns: Non-returnable special order item
• Support: Technical assistance available
• Delivery: Worldwide shipping options
• Packaging: Industrial protective packaging

Interbus Master FAQ

• What CPUs does this module support?
  It works with 140CPU11303, 140CPU43412A, and 140CPU53414B processors.
• How many devices can connect to the Interbus?
  The system supports multiple devices with 20m between each node.
• What do the different LED colors indicate?
  Green shows normal operation, red indicates faults, yellow warns of bus issues.
• Can I use this with existing Interbus networks?
  Yes, it’s compatible with existing Interbus DIN 66020 systems.
• What software version do I need?
  It requires Concept or ProWORX 32 software, version 2.5 SR2 or newer.

Technical inquiry? Contact: +86 158 8020 0923 for quick answers.
