Schneider Electric Modicon Quantum DC Output Module | 140DDO88500

Description

Schneider Electric Modicon Quantum 140DDO88500 DC Output Module

The Schneider Electric 140DDO88500 is a powerful DC discrete output module designed for the Modicon Quantum platform. It delivers robust performance with 12 outputs supporting a very wide voltage range. This module is ideal for controlling various DC loads in industrial automation. For complete wiring and configuration details, download the official manual: Download Modicon Quantum Manual.

Core Technical Specifications & Features

• Brand: Schneider Electric
• Model: 140DDO88500
• Product Type: DC discrete output module for the Modicon Quantum series.
• Output Channels: 12 outputs organized into 2 independent groups of 6.
• Output Logic: Utilizes negative logic (sink) for standard industrial compatibility.
• Output Voltage Range: Operates on a very wide range from 24 to 125 V DC.
• Output Current: Handles up to 0.75 A per point and a total of 6 A per module.
• Response Time: Offers a fast switching speed of 1 millisecond for both on and off.

Installation & Operational Data

• Addressing: Requires 1 input word and 1 output word in your PLC configuration.
• Bus Current: Consumption ranges from 375 mA to 650 mA depending on load.
• Power Dissipation: Calculate as 1 Watt plus 0.77 Watts for each active output.
• Fusing: Internal 4 A fuses protect each output group from overcurrent conditions.
• Operating Temperature: Reliably functions in a range of 0°C to 60°C (32°F to 140°F).

For immediate technical Support or a pricing Inquiry, please Contact: +86 158 8020 0923 via WhatsApp.

Packaging & Shipping Information

• Unit Package: Each module ships in its own individual box (PCE).
• Package Size: 12.28 x 6.42 x 1.77 inches (31.2 x 16.3 x 4.5 cm).
• Unit Weight: The shipping weight for one module is 18.2 ounces (515 grams).
• Shipping Methods: We ship worldwide using FedEx, UPS, and DHL for fast delivery.
• Warranty: This product comes with a solid 12-month warranty for your peace of mind.

Professional Frequently Asked Questions (FAQ)

• What is the maximum surge current for each output?
  Each output can handle a surge current of 4 Amps for a duration of 1 millisecond.
• Can this module directly drive tungsten (incandescent) lamps?
  Yes, it can drive tungsten loads up to 41W at 115V, 46W at 130V, and 8W at 24V.
• How are the output channels grouped for protection?
  The 12 outputs are divided into two separate groups of 6, each with its own 4A fuse.
• What is the logic level for an activated (ON) output?
  This is a sink (negative logic) module, so an active output will sink current to ground.
• Does the module require an external suppression diode for inductive loads?
  No, the module already includes internal protection, making an external diode unnecessary.

If you have any further questions, our Support team is ready to help. Contact: +86 158 8020 0923 for any Inquiry.
