Schneider Electric Modicon X80 BMENOS0300 – Switch Ethernet Module

Description

Schneider Electric Modicon X80 Ethernet Switch Module

The BMENOS0300 delivers reliable industrial networking for your automation system. This robust switch module connects seamlessly with BMEXBP backplanes. It ensures stable Ethernet/IP communication across three ports.

Technical Specifications

• Brand: Schneider Electric
• Model: Modicon X80 BMENOS0300
• Port Configuration: 3 Ethernet/IP ports
• Supply Voltage: 24V backplane
• Power Consumption: 3.3W at 25°C, 4.5W at 60°C
• Operating Temperature: 32°F to 140°F (0°C to 60°C)
• Storage Temperature: -40°F to 185°F (-40°C to 85°C)
• Protection Rating: IP20
• Operating Altitude: Up to 6,562 ft (2,000 m)

Key Features

• Triple-port Ethernet/IP switch for flexible connectivity
• Dual-function service port for network management
• Four status LEDs for instant module monitoring
• Standard module format for easy integration
• Industrial-grade construction for harsh environments
• 95% humidity operation without condensation

Installation & Compatibility

• Install in compatible BMEXBP series backplanes
• Utilizes 24V backplane power supply
• Follow standard Modicon X80 mounting procedures
• Ensure proper Ethernet cable specifications
• Verify all LED indicators show normal operation

Packaging & Delivery

• Unit Package: Individual protective packaging
• Dimensions: 2.17″ × 4.33″ × 4.53″ (5.5×11×11.5 cm)
• Unit Weight: 9.065 oz (257 g)
• Bulk Quantity: 15 units per master carton
• Shipping Options: FedEx, UPS, DHL express services

Frequently Asked Questions

• What networks support the BMENOS0300?
  The module works exclusively with Ethernet/IP device networks.
• How many devices can connect to this switch?
  Three Ethernet/IP devices connect simultaneously through the ports.
• What do the status LEDs indicate?
  They show module activity, errors, and network communication status.
• Can this switch operate in high temperatures?
  Yes, it maintains performance up to 140°F (60°C).
• What power source does the module require?
  It draws power directly from the 24V BMEXBP backplane.

Documentation & Support

• All purchases include 12-month product warranty
• For technical Support, Inquiry, Contact: +86 158 8020 0923
