Schneider Electric Quantum 140MSC10100 | Motion Control Module

Description

Schneider Electric 140MSC10100: Precision Motion Control for Robotics

Power your robotic systems with the Schneider Electric 140MSC10100 motion module. Designed for Modicon Quantum platforms, this module delivers advanced motion control for complex automation tasks. It handles position, speed, and torque control with exceptional accuracy.

Technical Specifications

Brand & Model: Schneider Electric 140MSC10100
Product Series: Modicon Quantum
Module Type: Motion Control Module
Control Types: Position, Velocity, Torque
Profiling: Cam profiling capability
Gearing: Electronic gearing function
Encoder Support: Incremental, Absolute, Resolvers
Power Supply: 24V DC
Operating Temperature: 0°C to 60°C
Operating Humidity: Up to 80% non-condensing
Maximum Altitude: 1000 meters
Application Focus: Robotics and precision motion
Communication: Modicon Quantum backplane

Installation & Integration

The 140MSC10100 integrates seamlessly into Modicon Quantum racks. It provides sophisticated motion control for robotic arms, CNC machines, and automated assembly lines. For technical integration support, Support, Inquiry, Contact: +86 158 8020 0923.

Motion Control FAQs

• Q1: What types of motion can this module control?
  A: It controls position, velocity, and torque for complete motion management.
• Q2: What is electronic gearing?
  A: It synchronizes multiple axes without mechanical gears for precise coordination.
• Q3: Which encoders are supported?
  A: Works with incremental, absolute encoders, and resolvers.
• Q4: What is the operating temperature range?
  A: It operates reliably from 0°C to 60°C (32°F to 140°F).
• Q5: What applications is this module best for?
  A: Ideal for robotics, packaging machines, and material handling systems.

Warranty & Shipping

This product includes a 12-month warranty. We ship internationally via FedEx, UPS, and DHL for fast delivery.

Download Motion Control Documentation

Get complete technical information:

• Full installation guidelines
• Programming examples and tutorials
• Configuration parameters
• Application case studies

Download the 140MSC10100 motion module manual here
