Schneider Electric 140ACO02000 Analog Output Module
Control your actuators with precision. The Modicon Quantum 140ACO02000 module gives you 4 reliable analog outputs. It sends standard 4-20mA signals to control valves, drives, and more. This module is built for fast and accurate performance in any industrial setting.
- Get the full details: Download the Product Manual (PDF)
- Need help? Contact Support: +86 158 8020 0923
Key Features of the 140ACO02000
This 140ACO02000 module has four output channels. Each channel is isolated for safety. It works with a wide power supply range (12-30V DC). Green LEDs show when a channel is active. Red LEDs quickly show any faults. It has a very fast update time of 3ms.
Detailed Technical Specifications
Brand: Schneider Electric
Product Model: 140ACO02000
Module Type: Analog Output
Number of Outputs: 4
Output Signal: 4-20 mA
Resolution: 12-bit (0-4096 counts)
Accuracy at 25°C: ±0.20% of full scale
Update Time: 3 milliseconds
Setting Time: 900 microseconds
Isolation: 500V AC between channels
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Power Required from Bus: 480 mA
External Power Supply: 12-30 V DC
Easy Installation
This module fits into a Modicon Quantum PLC rack. It needs 4 words of space in your PLC’s output configuration. Connect your external power (12-30V DC) for the outputs to work. For installation Inquiry, Contact: +86 158 8020 0923.
5 Frequently Asked Questions
1. What can I control with this module?
You can control devices that use a 4-20mA signal, like control valves, variable speed drives, or pressure regulators.
2. How is the output accuracy ensured?
The module has high accuracy (±0.20%) and checks for problems like open circuits on each output.
3. What is the difference between update time and setting time?
Update time is how fast the PLC updates the output value. Setting time is how quickly the output reaches its new value.
4. Can I use one output without using the others?
Yes. Each of the four outputs works independently. You can use any number of them at the same time.
5. What safety certifications does it have?
It is certified for use in demanding industrial environments (FM Class 1 Div 2, cUL, UL 508).
Warranty and Shipping
We provide a 12-month warranty on this product. Your item will be shipped safely using FedEx, UPS, or DHL.
Compare With Other Modules
If you need to measure temperature, see the 140ATI03000 Thermocouple Input Module.
For analog voltage inputs, check the 140AVI03000 Analog Input Module.
