Description
VS3202 KJ2201X1-BA1 12P3162X122 Redundant Logic Solver
???? Core Features
- ✅ SIL 3-certified per IEC 61508/61511
- ???? Redundant architecture (4-slot configuration)
- ???? Cybersecurity-ready design
- ???? Scalable for any application size
???? Technical Specifications
????️ -40°C to 70°C Operating Temp
???? 5-95% Humidity (non-condensing)
⚡ 24VDC ±20% Input
????️ IP20 Rating + Conformal Coating
???? 5A Max Total Current
???? 1.20kg Weight
????️ Installation Details
| Mounting Slots | Odd-numbered (1/3/5/7) |
| Vibration Resistance | 1mm peak (5-16Hz) 0.5g (16-150Hz) |
???? Typical Applications
- Oil & Gas Emergency Shutdown Systems
- Chemical Plant Safety Instrumentation
- Power Generation Critical Controls
