Description
Product Overview
- The easYgen-2500 is an operator interface for breaker control from the easYgen-3000 series.
- It features a color LCD display for clear genset monitoring.
- Works with 12/24 V DC power (8 to 40 V DC range).
- Maximum power consumption is only 19 W.
- Mounts on a front panel – easy to see and use.
- Offers 32 discrete inputs/outputs and 16 analog inputs / 4 analog outputs.
Series Highlights – easYgen-3000 Family
- The easYgen-3000 series is a very flexible genset control and protection package.
- Works for many applications – from single emergency gensets to 32 parallel units.
- Supports isochronous load sharing in island mode or with utility.
- Typical uses: emergency standby, cogeneration, marine, prime power, peak shaving, import/export.
Two Available Versions
- easYgen-3100 / 3400 – back‑panel mount with rugged aluminum housing. Great for harsh or tight spaces.
- easYgen-3200 / 3500 – front‑panel mount with sealed soft keys and large backlit multilingual graphical display.
Key Features
- True RMS sensing for generator, bus, and mains voltage/current.
- Complete engine/generator protection, metering, and mains monitoring.
- LogicsManager™ – combine measured values, internal conditions, and I/O states with Boolean logic and timers.
- Load share up to 32 gensets in island mode or paralleled to utility.
- Configurable start/stop sequencing with kW/kvar load sharing.
- Communication to engine ECUs, SCADA, external I/O, and RP‑3000 remote panel.
- Supports CANopen, J1939, Modbus RTU, and modem.
- Easy‑to‑read graphical display with selectable languages (easYgen‑3200/3500).
Technical Specifications – Tree Structure
- Brand & Model: Woodward / easYgen-2500 (part of easYgen-3000 series)
- Product Type: Operator Interface / Breaker Control
- Part Number reference: 8440-1934
- Power Supply:
- Voltage: 12/24 V DC (range 8 to 40 V DC)
- Max consumption: 19 W (easYgen-2500) / 17 W (other models)
- Measurement Accuracy:
- Voltage AC input: 120 VAC and 480 VAC true RMS – Class 1 accuracy
- Current AC input: 1 A or 5 A true RMS, isolated – Class 1 accuracy
- I/O Capabilities (easYgen-2500):
- External discrete inputs: 32
- External discrete outputs: 32
- External analog inputs: 16
- External analog outputs: 4
- General I/O Specifications:
- Discrete inputs (isolated): 12/24 V DC (8 to 40 V DC)
- Relay outputs: dry contacts, resistive load 2 A at 24 V DC and 250 V AC
- Analog inputs: 0 to 500 ohms, 0 to 20 mA
- Analog outputs (isolated): ±10 V / ±20 mA / PWM
- Environmental Tolerance:
- Operating temperature: -20°C to +70°C (-4°F to +158°F)
- Storage temperature: -30°C to +80°C (-22°F to +176°F)
- Humidity: 95% non‑condensing
- Housing & Mounting:
- easYgen-3200/3500: Front panel mounting, plastic housing, IP66 front / IP20 back. Dimensions: 282 × 217 × 99 mm. Weight ≈1,850 g.
- easYgen-3100/3400: Back panel mounting, sheet metal housing, IP66 front / IP20 back. Dimensions: 250 × 228 × 84 mm. Weight ≈2,150 g.
- Communication Protocols: CANopen, J1939, Modbus RTU, modem support
Installation Guide
- For front‑panel mount: cut panel opening, insert unit, and secure with clamps.
- For back‑panel mount: fix the aluminum housing directly to the cabinet backplate.
- Connect DC power (8‑40 V) to the designated terminals – observe polarity.
- Wire voltage inputs (120 V or 480 V AC) and current inputs (1 A or 5 A CTs).
- Connect discrete and analog I/O as needed for your application.
- Use shielded cables for analog signals and communication lines.
Debug & Maintenance Simplicity
- Color LCD shows real‑time values, alarms, and events – easy to troubleshoot.
- LogicsManager™ lets you test logic online without stopping the genset.
- Front‑panel sealed soft keys work in dusty or wet environments.
- Remote monitoring via RP‑3000 panel or SCADA over Modbus.
- Firmware updates via serial or USB (check model).
Compatibility Information
- Works with any genset ECU supporting J1939 or CANopen.
- Compatible with Modbus RTU devices (PLC, HMI, SCADA).
- Can integrate with Modicon Quantum PLCs via Modbus – see Modicon Quantum series.
- Supports remote I/O expansion via external modules.
Certifications & Standards
- Complies with CE, UL 508, CSA C22.2 No 142, EN/IEC 61131‑2.
- Accuracy Class 1 for voltage and current measurements.
- IP66 front sealing – protects against water jets and dust.
- IP20 back – safe for indoor cabinet installation.
Package Contents
- 1x easYgen-2500 operator interface (or chosen model)
- Mounting hardware (clamps or screws)
- Quick start guide
- Communication cable (optional – check seller)
- No external CTs or power supply included.
Warranty & Shipping Methods
- 12-month warranty against manufacturing defects.
- Express couriers: FedEx, UPS, DHL worldwide.
- Same‑day dispatch for orders before 2 PM (GMT+8).
- Delivery in 3‑7 business days to most countries.
- Tracking number provided by email.
Typical Application Scenarios
- Emergency standby generators for hospitals or data centers.
- Cogeneration (CHP) plants – heat and power together.
- Marine ship/shore power connection and management.
- Island prime power for remote mines or villages.
- Utility paralleling with peak shaving and import/export control.
Diagnostic Capabilities
- Continuous self‑monitoring of voltage, current, frequency, and power.
- Alarm log stores last 100 events with time stamp.
- Real‑time phasor display helps diagnose CT wiring issues.
- Modbus diagnostic registers show communication errors.
- Built‑in engine ECU fault code reading via J1939.
Frequently Asked Questions (FAQ)
- Q1: Can I use easYgen-2500 with a single genset only?
- A1: Yes. It works for single gensets and also supports up to 32 units in parallel.
- Q2: What is the difference between easYgen-2500 and easYgen-3200?
- A2: easYgen-2500 is an operator interface. easYgen-3200 is a full controller with built‑in protection and load sharing.
- Q3: Does this unit support remote start from a dry contact?
- A3: Yes. Use one of the 32 discrete inputs to trigger remote start.
- Q4: Can I connect the unit to a building management system?
- A4: Yes. Use Modbus RTU to connect to any BMS or PLC.
- Q5: What happens if DC power drops below 8 V?
- A5: The unit will shut down. Use a battery charger to maintain voltage.
Buying Guide & Selection Tips
- Choose easYgen-2500 if you already have a separate genset controller and need an operator panel.
- For full control + display, pick easYgen-3200 (front panel) or easYgen-3100 (back panel).
- Use back‑panel version (3100/3400) for harsh environments – rugged aluminum housing.
- Check your CT secondary rating: select 1 A or 5 A model accordingly.
- Buy spare communication cables and fuses for quick field replacement.
- Order from authorized distributors to ensure genuine Woodward products.
