Yokogawa AAM10 Current Voltage Input Module CENTUM Series Reliable I O

Description

Product Snapshot

The AAM10 is a current and voltage input module.
It works with Yokogawa Centum VP systems.
It reads field signals with high stability.

• Brand: Yokogawa
• Model: AAM10
• Series: CENTUM Control Platform
• Module type: Current Voltage Input

Configuration Breakdown

• AAM10
  • AAM
    • Analog measurement module
  • 10
    • Simplified input type
  • Software setting
    • Signal type set by system tools

Signal Handling

• Current input: 4 to 20 mA DC
• Voltage input: 1 to 5 V DC
• Over range support: Yes
• Two wire transmitter support

Electrical Characteristics

• Voltage resistance: 1 MΩ
• Current resistance: 250 Ω
• Allowable voltage: -10 to 30 V DC
• Allowable current: Up to 40 mA

Transmitter Power

• Supply output: 25.0 to 25.5 V DC
• Output limit: 60 mA or less
• External power: Not required

Measurement Accuracy

• Voltage error: ±4 mV
• Current error: ±16 µA
• Temperature drift per 10 °C
  • Voltage: ±8 mV
  • Current: ±32 µA

Speed and Isolation

• Data refresh: 50 ms
• Signal isolation: System to field
• Withstand voltage: 1500 V AC per minute

Power and Load

• Internal supply: 5.0 V DC
• Current draw: 250 mA or less
• Low heat design

Installation Details

• Mounting: I O module nest
• Wiring: M4 screw terminals
• Setup: Software configuration

Extra Technical Notes

• Compatible with MTL 728 barrier
• Loop wiring resistance under 10 Ω
• System software R2.07 or later
• Voltage mode enables signal sharing

Key Benefits

• Stable signal reading
• Simple wiring layout
• Good noise immunity
• Easy system scaling
• Long service life

Typical Applications

• Pressure transmitters
• Flow measurement loops
• Temperature conversion
• General process signals

Warranty and Shipping

• Warranty: 12 months
• Delivery: FedEx, UPS, DHL
• Industrial packing included

Professional FAQ

• Is this module good for basic loops
  Yes. It fits simple and stable signal tasks.
• Can it power field transmitters
  Yes. Built in supply supports two wire devices.
• How to share one current signal
  Use shunt resistance and voltage mode.
• When should voltage input be chosen
  Choose it for shared or long cable runs.
• What should buyers check first
  Confirm system software version and signal type.
