Description
Bently Nevada 3300 XL 11mm Probe: Long-Reach Vibration Sensing
Product ID Decoder: 330702-00-10-90-11-00
- ▸ 00 – 0.0″ unthreaded section
- ▸ 10 – 1.0″ case length
- ▸ 90 – 9.0 meter cable (29.5 ft)
- ▸ 11 – ClickLoc + FluidLoc sealed
- ▸ 00 – Standard approvals
Critical Specifications
- Thread: ½-20 UNF armored
- Resistance: 8.5Ω ±1.1 (9m length)
- Temp Range: -51°C to +177°C
- Cable Type: 75Ω triaxial FEP
- Min Bend: 25.4mm (1.0″) radius
- Weight: 0.17 kg
Key Advantages
- 9m reach for hard-to-access locations
- Armored cable withstands abrasion
- FluidLoc blocks oil migration
- PPS tip resists chemical corrosion
- Viton O-ring for pressure sealing
Installation Guide
- ⚙️ Max torque: 15.2 N•m (133 in-lb)
- ???? Thread engagement: 0.750″ max
- ⚠️ Avoid: Below -34°C to protect seals
- ???? Connectors: Finger-tight only
Support & Delivery
- 12-month warranty
- Fast shipping: FedEx/UPS/DHL
- Made in USA quality
Expert Questions Answered
- Q: Can I cut the 9m cable shorter?
A: No – will damage calibration - Q: Saltwater resistance?
A: 304 SST case resists corrosion - Q: Vibration tolerance?
A: Withstands 15g @ 2000Hz - Q: Replacement O-rings?
A: Viton rings available separately - Q: Lead time for M16 version?
A: 2-3 weeks typically
