Bently Nevada 3300 XL 11mm FluidLoc Probe: Hazardous Environment Solution
Product Overview
New Bently Nevada 330707-00-24-10-11-00 proximity probe. Made in USA with FluidLoc cable and connector protector. Designed for challenging industrial conditions.
Part Number Breakdown
330707-00-24-10-11-00 means:
- 330707: 5/8-18 UNF thread (no armor)
- 00: 0″ unthreaded section
- 24: 2.4″ case length
- 10: 1.0m cable (3.3 ft)
- 11: ClickLoc with protector + FluidLoc cable
- 00: No agency approvals
Key Specifications
- Electrical Resistance: 5.9Ω ±0.5
- Thread Engagement: Max 0.938″
- Temp Range: -51°C to +177°C | Min: -34°C
- Install Torque: 15.2 N•m recommended
- Cable Type: FluidLoc triaxial (75Ω)
- Bend Radius: Min 25.4mm
- Weight: 0.17 kg
Installation Guide
- Max torque: 45.2 N•m (400 in•lb)
- Connector torque: Finger tight only
- Keep above -34°C during install
Shipping Details
New in factory packaging. Ships via FedEx/UPS/DHL. Weight 0.17kg. 12-month warranty. COO available.
Technical Questions
- Q: What makes FluidLoc cable special?
A: Resists liquids and chemicals better than standard cables. - Q: Is this probe approved for hazardous areas?
A: No agency approvals (option 00). Check requirements for your application. - Q: What’s the connector protector for?
A: Protects connection from damage during operation. - Q: Can I use this in underwater applications?
A: Not recommended. Contact for pressure testing options. - Q: What’s the max shaft size for measurement?
A: No set limit, but minimum target is 8.9mm diameter.
