Bently Nevada 3300 XL Proximity Probe: Industrial-Grade Monitoring
Product Highlights
330707-00-24-10-12-05 probe with FluidLoc cable and multiple global approvals. Made in USA. 1.0m length. Ideal for harsh industrial environments.
Part Number Details
Full ID: 330707-00-24-10-12-05
- 330707: 5/8-18 UNF thread, no armor
- 00: 0 inch unthreaded section
- 24: 2.4 inch case length
- 10: 1.0 meter cable
- 12: ClickLoc + FluidLoc cable
- 05: Multiple agency approvals
Key Specifications
- Electrical: 5.9Ω resistance ±0.5
- Thread: 5/8-18 UNF | Max engagement: 0.938″
- Temperature: -51°C to +177°C | Min: -34°C
- Installation: 15.2 N•m torque recommended
- Bend Radius: 25.4mm minimum
- Connector: Finger tight only (0.565 N•m max)
- Weight: 0.17 kg
Special Features
- FluidLoc chemical-resistant cable
- Global safety approvals
- PPS plastic probe tip
- Stainless steel housing
- Viton O-ring seal
Installation Notes
- Apply max 45.2 N•m torque
- Keep cable bends >25.4mm
- Avoid temperatures below -34°C
- Use proper thread engagement
Shipping & Support
Factory new. Ships worldwide via FedEx/UPS/DHL. 0.17kg weight. 12-month warranty. COO available.
Technical Questions
- Q: What approvals does this model have?
A: Multiple global certifications (option 05). - Q: Difference between FluidLoc and standard cable?
A: FluidLoc resists oils and chemicals better. - Q: Maximum pressure rating?
A: Not rated by default. Contact for pressure testing. - Q: Can I use this with extension cables?
A: Yes, compatible with 3300 XL systems. - Q: Is calibration required?
A: Ships pre-calibrated. Yearly checks recommended.
