Description
Bently Nevada 3300 XL 5m Vibration Probe – Reliable Machinery Monitoring
Precision sensor for industrial equipment health checks. Made in USA. Perfect for turbines, pumps, and compressors.
Part Number Decoded: 330701-00-10-50-01-05
- → 330701: Base model
- → 00: 0″ unthreaded length
- → 10: 1.0″ case length
- → 50: 5.0 meter cable
- → 01: ClickLoc + standard cable
- → 05: Multiple safety approvals
Key Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 11mm Probe
- Part No: 330701-00-10-50-01-05
- Cable Resistance: 7.2Ω ±0.8Ω
- Thread Size: 1/2-20 UNF
- Max Torque: 15.2 N·m (133 in·lb)
- Bend Radius: 25.4mm min
- Tip Material: PPS plastic
- Weight: 0.17 kg
- Compatibility: Works only with 5m Proximitor sensors
Performance Features
- ???? 75 Ω triaxial cable for clean signals
- ???? Viton O-ring pressure seal
- ❄️ Avoid below -34°C for seal protection
- ???? Finger-tight connector (max 0.565 N·m)
Shipping & Warranty
- ???? 12-month warranty
- ???? Fast worldwide delivery: FedEx • UPS • DHL
- ⚖️ Light package: 0.17kg (low shipping cost)
Expert FAQ
Q: What is standard cable vs FluidLoc?
A: Standard cable is for dry areas. FluidLoc resists oils/chemicals.
Q: Can I cut the cable length?
A: No. Cutting changes electrical properties and voids warranty.
Q: Is calibration required?
A: Comes factory-calibrated. Yearly recalibration recommended.
Q: What approvals does Option 05 include?
A: Meets multiple industrial safety standards (contact for list).
Q: Can I use in explosive environments?
A: Not certified for hazardous areas. Check approvals first.
