11 mm Proximity Probes Bently Nevada 330707-00-24-10-02-05

Description

Bently Nevada 3300 XL 11mm Triaxial Proximity Probe

Essential Features

New 330707-00-24-10-02-05 with 1.0m triaxial cable. 5/8-18 UNF threaded probe for industrial vibration monitoring. Made in USA.

Technical Specifications

• Resistance: 5.9 Ω ±0.5 Ω
• Cable Type: 75Ω triaxial FEP
• Thread Size: 5/8-18 UNF
• Case Length: 2.4 in (61 mm)
• Temp Range: -51°C to +177°C
• Min Bend Radius: 25.4 mm

Full Model Code Breakdown

• 330707 – 11mm probe base
• 00 – 0″ unthreaded length
• 24 – 2.4″ case length
• 10 – 1.0m cable
• 02 – ClickLoc connector
• 05 – Multiple approvals

Installation Details

• Mounting Torque: 15.2 N•m (133 in•lb)
• Max Torque: 45.2 N•m (400 in•lb)
• Thread Engagement: 0.938 in min
• Seal Type: Viton O-ring
• Weight: 0.17 kg

Performance Data

• Pressure Seal: Differential pressure design
• Cable Options: 1m, 5m or 9m lengths
• Tip Material: PPS plastic
• Case Material: 304 stainless steel
• Low Temp Warning: Avoid below -34°C

Compliance & Packaging

Includes multiple agency approvals. 12-month warranty included.

Technical FAQs

• Q: What does triaxial cable mean?
  A: Three-layer shielding for better signal protection.
• Q: Minimum thread engagement?
  A: Requires 0.938 inches minimum for secure mounting.
• Q: Cold temperature limitation?
  A: Avoid below -34°C to protect seals.
• Q: Different cable lengths available?
  A: Yes: 1m, 5m or 9m options.
• Q: What approvals does it have?
  A: Multiple agency certifications (Option 05).
