Description
Bently Nevada XL Probe with Extended Body for Deep Mounting
Industrial-grade 11mm vibration sensor with 3-inch stainless steel body and protective connector. Made in USA for reliable machinery monitoring.
Product Identification
Brand: Bently Nevada
Series: 3300 XL 11mm
Full Product No: 330707-20-30-10-01-05
Configuration Details:
→ 330707: Base model
→ 20: 2.0″ unthreaded section
→ 30: 3.0″ case length
→ 10: 1.0m cable
→ 01: ClickLoc with protector
→ 05: Multiple approvals
Technical Specifications
- Cable Length: 1.0 meter (3.3 ft)
- Electrical Resistance: 5.9 Ω ±0.5
- Thread Type: 5/8-18 UNF
- Case Material: 304 Stainless Steel
- Weight: 0.17 kg
- Min Bend Radius: 25.4mm (1 inch)
Installation Guide
- Recommended Torque: 15.2 N•m (133 in•lb)
- Maximum Torque: 45.2 N•m (400 in•lb)
- Thread Engagement: Max 0.938 inch
- Warning: Do not install below -34°C (-30°F)
- Connectors: Hand-tighten plus 1/4 turn
Compatibility
- Bently Nevada 3300 monitoring systems
- Machinery with deep mounting points
- Hazardous locations (multiple approvals)
Package Includes
- 1 proximity probe with 1m cable
- ClickLoc connector with protector
- Optional COO certificate
- 12-month manufacturer warranty
Shipping Options
- Weight: 0.17 kg
- FedEx Priority
- UPS Express
- DHL Worldwide
FAQ
Q: What makes this probe different?
A: Extended 3-inch body with 2-inch smooth section for deep installations.
Q: What connector protection is included?
A: Comes with protective cover for the ClickLoc connector (option 01).
Q: Can I use this in explosive areas?
A: Yes, multiple safety approvals (option 05) cover hazardous locations.
Q: Why the long unthreaded section?
A: Allows flexible positioning in deep mounting holes.
Need detailed specs? Get the complete technical manual:
Download Product Guide
