Schneider Electric 140DSI35300: Reliable 32-Point DC Input Module
Upgrade your automation system with the Schneider Electric 140DSI35300. This high-quality discrete input module is designed for the Modicon Quantum platform. It offers 32 digital inputs for 24V DC signals. Perfect for monitoring sensors and switches in industrial applications.
Top Features
- 32 Input Channels: Monitor multiple devices with one module
- 24V DC Operation: Standard industrial voltage compatibility
- Fast Response: Quick 2.2ms detection time
- Broken Wire Detection: Advanced diagnostic capability
- LED Indicators: Easy status monitoring for all channels
Complete Technical Specifications
Brand & Model: Schneider Electric 140DSI35300
Product Series: Modicon Quantum
Module Type: Discrete Input Module
Input Channels: 32 points
Input Voltage: 24V DC (20-30V range)
Logic Level 1: ≥11V DC at ≥2.5mA
Logic Level 0: ≤5V DC at ≤1.2mA
Response Time: 2.2ms (ON), 3.3ms (OFF)
Isolation: 1780Vrms (group to bus)
Addressing: 4 input words
Operating Temperature: 0°C to 60°C
Certifications: UL 508, CSA, FM Class 1 Div 2
Power Consumption: 250mA bus current
Installation & Compatibility
The 140DSI35300 module installs easily into Modicon Quantum racks. It features 4 isolated groups for flexible wiring. The module works with standard 24V DC sensors and switches. For installation support, Support, Inquiry, Contact: +86 158 8020 0923.
Technical FAQs
Q1: What is the operating voltage range?
A: It works with 20-30V DC, with 24V DC as the standard rating.
Q2: How many input words does it require?
A: The module needs 4 input words in the PLC program.
Q3: What is broken wire detection?
A: This feature helps identify disconnected wires or faulty sensors.
Q4: What are the isolation ratings?
A: 1780Vrms between groups and bus, 500Vrms between groups.
Q5: Can it handle voltage spikes?
A: Yes, it withstands up to 45V for 10ms pulses.
Warranty & Shipping Info
All orders include a 12-month warranty. We ship globally using FedEx, UPS, and DHL for reliable delivery.
Download Full Documentation
Get complete technical details:
- Wiring diagrams and installation guide
- Technical specifications and ratings
- Application examples and best practices
- Safety instructions and certifications
Click here to download the 140DSI35300 manual
