Schneider Electric 140EIA92100: AS-Interface Master for Smart Sensor Networks
Simplify your sensor and actuator wiring with the Schneider Electric 140EIA92100 AS-Interface master module. This powerful module connects your Modicon Quantum PLC to 124 I/O points using just 2 wires. Reduce installation costs and complexity with this innovative bus system.
Why Choose This AS-i Master?
- Massive I/O Capacity: Control up to 124 inputs and 124 outputs
- Simple 2-Wire Network: Easy installation and maintenance
- Fast Cycle Time: 5ms maximum update rate
- Long Distance: 100 meter range without repeaters
- Visual Monitoring: 32 LEDs show slave status and I/O states
Technical Specifications
Brand & Model: Schneider Electric 140EIA92100
Product Series: Modicon Quantum
Module Type: AS-Interface Master Module
AS-i Version: V1, Profile M2
I/O Capacity: 124 inputs + 124 outputs
Slave Devices: Up to 31 slaves
Supply Voltage: 30V DC via AS-i line
Cycle Time: 5ms maximum
Bus Length: 100 meters (328 ft)
Data Rate: 167 kbit/s
Connection: SUB-D 9-pin male connector
Current Consumption: 60-100 mA at 30V DC
Operating Temperature: 0°C to 60°C
Protection Rating: IP20
Modules per PLC: 4 local/remote, 2 distributed
Network Integration
The 140EIA92100 creates a cost-effective sensor network using standard AS-i cables and components. It features reverse polarity protection for safe operation. Each slave status is clearly shown by LED indicators. For network design assistance, Support, Inquiry, Contact: +86 158 8020 0923.
Technical FAQs
- Q1: How many devices can connect to this master?
A: It supports up to 31 AS-i slave devices on the network. - Q2: What is the maximum network distance?
A: The AS-i cable can run 100 meters without needing repeaters. - Q3: How fast is the data update?
A: The complete network updates every 5 milliseconds maximum. - Q4: What type of connector does it use?
A: It uses a standard SUB-D 9-pin male connector for AS-i connection. - Q5: Can multiple masters be used in one system?
A: Yes, up to 4 masters in local/remote racks or 2 in distributed drops.
Warranty & Shipping
We provide a 12-month warranty on this module. Orders ship via FedEx, UPS, and DHL for reliable worldwide delivery.
Get Complete System Documentation
Download everything you need:
- Complete installation guide
- Network configuration instructions
- Wiring diagrams and cable specifications
- Troubleshooting and maintenance tips
Download the 140EIA92100 technical manual here
