Description
Product Overview
The Schneider Electric 170ANR12091 is an I/O base unit from the Modicon Momentum series. It mixes digital and analog control in one compact device. This unit handles both simple on/off signals and precise analog values. Many industries use it for flexible automation tasks. For larger systems, consider the Modicon Quantum series.
Key Features at a Glance
- All-in-one I/O base unit design
- No separate adapter module needed
- Works with Modicon Momentum PLCs
- Suitable for clean indoor environments
- Easy to install on DIN rail
Technical Specifications
Brand: Schneider Electric
Series: Modicon Momentum
Model: 170ANR12091
Type: I/O Base Unit
Weight: 1.00 lbs (0.45 kg)
EAN: 3595862053402
Input / Output Configuration
- Discrete Inputs: 8 points (digital on/off)
- Discrete Outputs: 8 points (digital on/off)
- Analog Inputs: 6 channels (continuous values)
- Analog Outputs: 4 channels (continuous control)
- Total I/O count: 26 points
Temperature & Humidity Limits
- Operating temperature: 0 to 60°C (32 to 140°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Operating humidity: 95% non-condensing max
- Storage humidity: 95% non-condensing max
Altitude & Environment
- Max operating altitude: 5000 meters (16,400 feet)
- Max storage altitude: 5000 meters
- Required environment: Clean indoor area
- Avoid: Corrosive chemicals or heavy dust
Installation & Compatibility
Mount the 170ANR12091 on a standard DIN rail inside a control panel. Connect field devices directly to the built-in terminals. This base unit works with any Modicon Momentum processor. No separate I/O adapter is required. Keep the unit away from heat sources and moisture. For more advanced features, explore the Modicon Quantum product line.
Typical Applications
This I/O base unit fits many factory automation tasks. Common uses include:
- Conveyor control systems
- Packaging machines
- HVAC monitoring and control
- Pump and valve stations
- Small process skids
Package Contents
- One Schneider Electric 170ANR12091 I/O base unit
- One product label with EAN code
- Installation guide (printed sheet)
Warranty & Shipping
We offer 12 months warranty on this 170ANR12091 unit. This covers manufacturer defects only. It does not cover misuse or improper installation.
We ship worldwide using FedEx, UPS, or DHL. You will receive a tracking number within 24 hours. Delivery takes 3 to 7 business days for most locations.
Frequently Asked Questions (FAQ)
Does the 170ANR12091 need a separate power supply?
Yes, this base unit requires an external 24V DC power supply. The power supply is not included in the package.
What type of signals do the analog inputs accept?
The 170ANR12091 analog inputs accept 0-10V or 4-20mA signals. You must configure each channel during programming.
Can I use this base unit outdoors?
No, the 170ANR12091 is designed for clean indoor use only. Outdoor use requires an additional weatherproof enclosure.
How do I know if my unit is faulty?
Check the LED status indicators on the front panel. No LED activity suggests a power problem. Erratic I/O may indicate a configuration error.
What is the difference between discrete and analog I/O?
Discrete I/O turns things on or off like a light switch. Analog I/O measures or controls variable values like temperature or speed.
Selection Guide & Buying Advice
Choose the Schneider Electric 170ANR12091 if you need both digital and analog I/O in one unit. It saves panel space and reduces wiring. For pure digital control only, consider a lower cost discrete-only model. For more analog channels, look at the 170ANR12090 series.
Check your processor compatibility before ordering. This 170ANR12091 works with all Modicon Momentum CPUs. Verify your operating temperature does not exceed 60°C. For hot environments, add panel cooling or choose a high-temp model. For high-end process applications, evaluate the Modicon Quantum series for more scalability.
