Schneider Electric 170DNT11000 Profibus DP Adaptor
Schneider Electric 170DNT11000 connects your Modicon Momentum PLC to Profibus DP networks. This compact adaptor sends data at speeds from 9.6 to 12 Mbit/s. It works with twisted pair cables in multidrop or ring layouts. Use it to link up to 126 field devices in one network.
This adaptor also integrates seamlessly with Modicon Quantum systems when used as remote I/O. The 170DNT11000 acts as a slave on the Profibus DP bus.
Core Features
- Brand: Schneider Electric
- Series: Modicon Momentum
- Model: 170DNT11000
- Product Type: Communication Adaptor
- Protocol: Profibus DP
Technical Data at a Glance
- Speed Range: 9.6 kbit/s up to 12 Mbit/s
- Cable Type: Twisted pair
- Topology Support: Multidrop and ring
- Max Devices: 126 per network
- Max Cable Length: 1200 meters
- Address Setting: Switch-selectable (easy)
- Error Check: CRC-16 control parameter
- Connector: 1 x 9-pin SUB-D
Environmental & Physical Specs
- Protection: IP20 (indoor use only)
- Work Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Humidity Limit: 95% without condensation
- Weight: 0.19 lbs (0.09 kg)
- Certifications: UL, CSA
Installation & Wiring Guide
- Mount the 170DNT11000 inside a dry control panel.
- Do not expose it to water or dripping oil.
- Use twisted pair cable with proper shielding.
- Connect the 9-pin SUB-D plug to your Profibus network.
- Set the device address using the onboard switches.
- Keep total cable length under 1200 meters.
- Terminate both ends of the main cable.
Network Capacity & Signal Quality
- Supports up to 126 devices (repeaters may add more).
- Signal integrity checks use CRC-16 error detection.
- Bad data packets get rejected automatically.
- Works well in noisy factories due to differential signals.
- Ideal for mixed I/O, drives, and remote racks including Modicon Quantum systems.
Typical Applications
- Connecting Momentum PLC to Profibus DP master
- Adding remote I/O stations to a central controller
- Linking variable speed drives to a SCADA system
- Expanding machine networks in packaging lines
- Integrating third-party Profibus DP devices with Modicon Quantum
Troubleshooting & Diagnostics
- Check the green LED for bus activity.
- No LED means no power or wrong wiring.
- Verify the address switch matches your configuration.
- Test cable continuity if devices go offline.
- Use a Profibus tester to check signal quality.
Package Contents
- 1 x Schneider Electric 170DNT11000 adaptor
- 1 x user manual (quick start guide)
- No cables or connectors included
Warranty & Fast Delivery
- 12 months warranty against factory defects.
- We ship worldwide via FedEx, UPS, and DHL.
- Tracking number sent within 24 hours.
Frequently Asked Questions (FAQ)
Q1: Can I use 170DNT11000 with a Siemens S7-1200 PLC?
Yes, if your S7-1200 has a Profibus DP master module (like CM 1243-5).
Q2: What happens if cable length exceeds 1200 meters?
Signal becomes weak or unstable. Add a Profibus repeater to go further.
Q3: Does this adaptor need external 24V power?
Yes, the 170DNT11000 draws power from the Momentum backplane. No extra supply is needed.
Q4: Can I use 170DNT11000 in outdoor cabinets?
No. IP20 rating means indoor use only. Protect it from rain or dust.
Q5: Why does my network stop at high speed (12 Mbit/s)?
Reduce cable length or use better shielded cable. Some old devices may not run at 12 Mbit/s.
Q6: Is 170DNT11000 compatible with Modicon Quantum?
Yes, use it as a remote I/O adaptor connected to a Quantum Profibus DP master.
Selection Guide & Expert Advice
- For long networks: Choose 170DNT11000 with 1200m cable support.
- For very high speed (12 Mbit/s): Keep each segment under 100 meters.
- For legacy systems: This adaptor works with most Profibus DP masters from Siemens, ABB, or Emerson.
- For harsh vibration areas: Use locking SUB-D connectors.
- For easy commissioning: Set address switches before mounting the unit.
