Description
Bently Nevada Long-Reach Vibration Sensor: Precision Protection
Critical Machinery Monitoring Solution
New factory-sealed Bently Nevada 21505-00-72-10-02 proximity probe. Features extra-long 7.2″ case for hard-to-reach installations. Industrial-grade protection with 12-month warranty.
Complete Specifications
- Manufacturer: Bently Nevada
- Full Part No: 21505-00-72-10-02
- Configuration Details:
- 00: Zero unthreaded length
- 72: 7.2 inch extended case
- 10: 1.0 meter cable (39±4 inches)
- 02: Miniature coaxial connector
- Sensing Range: 0.25mm to 2.0mm
- Accuracy: ±9.5% including interchangeability
- Output: 200mV/mil (7.87V/mm)
- Response Speed: 10kHz (-5%)
- Temp Range: -34°C to +177°C (probe)
Industrial-Grade Design
- Extended 7.2″ stainless steel case
- 8mm threaded tip (3/8-24)
- Armored cable for crush resistance
- Chemical-proof (acids, oils, solvents)
- 95% humidity operation
Simple Installation
- Position 0.25mm from target surface
- Secure with 3/8-24 threads
- Connect coaxial cable
- Power with -24V DC (±10%)
Expert Answers
Q: Why the 7.2″ case length?
A: For installations needing extra reach past insulation or guards
Q: Temperature limits?
A: Probe survives -34°C to +177°C (-30°F to +350°F)
Q: Cable protection?
A: Stainless steel armor prevents damage in tough areas
