Allen-Bradley PowerFlex 40P 22D-B012N104 Variable Frequency Drive
Description
The Allen-Bradley 22D-B012N104 is a high-performance 3 HP (2.2 kW) adjustable frequency drive from the PowerFlex 40P series. Designed for three-phase 240V AC input, this drive delivers sensorless vector control for superior torque and speed regulation. Its removable MOV supports ungrounded systems, while the integral brake resistor ensures dynamic braking. With autotuning and encoder feedback, it adapts to motor characteristics for optimized performance.
Technical Data
- Brand: Allen-Bradley (Rockwell Automation)
- Model: PowerFlex 40P 22D-B012N104
- Input Voltage: 240V AC, 3-Phase
- Output Power: 3 HP (2.2 kW)
- Current Rating: 12.0 A
- Enclosure: Open Type (IP20, Panel Mount)
- Frame Size: B
- Control Type: Sensorless Vector
- Braking: Built-in Dynamic Brake Resistor
- Protections: Motor Overload, Ground Fault, 6000V Transient
- Operating Temp: 0°C to 40°C (32°F to 104°F)
Key Features
- Autotune for motor compatibility
- 150% overload capacity for heavy starts
- Relay pre-charge reduces inrush current
- Closed-loop control with encoder feedback
- 6000V transient protection for durability
Installation & Compatibility
Mount in a ventilated panel (IP20). Compatible with 3-phase motors up to 3 HP. Wiring diagrams included in manual. Not CE-filtered – check local regulations.
Package & Warranty
- 1x PowerFlex 40P Drive (22D-B012N104)
- 1x User Manual
- 12-month warranty from shipment date
Shipping: FedEx, UPS, or DHL (express options available).
Similar Models
- 22D-D017H204 – 5 HP, 480V AC Input
- 22D-D017N104 – 5 HP, 240V AC Input
