Description
Product Description
- Bently Nevada 3300/55-03-01-15-15-00-00-01-00 is a dual velocity monitor for rotating machinery protection.
- Designed for the 3500 Series monitoring platform.
- Provides stable velocity measurement for early fault detection.
- Supports two independent channels for higher system reliability.
- Ideal for continuous industrial vibration monitoring.
Key Technical Data
- Brand: Bently Nevada
- Model: 3300/55-03-01-15-15-00-00-01-00
- Series: 3500
- Product type: Dual velocity monitor I/O module
- Input signal range: -10 Vdc to +10 Vdc
- Channel A range: 0 to 200 µm peak-to-peak
- Channel B range: 0 to 200 µm peak-to-peak
- Resolution: 0.3662 A per bit
- Power consumption: 7.7 watts
Measurement Performance
- Transducer type: 9200 or 74712 velocity sensors
- Sensitivity: 500 mV per inch per second
- Input impedance: 10 kΩ
- High linear response across full scale range
- Low noise design improves signal clarity
Environmental & Reliability Ratings
- Operating temperature: 0°C to +65°C
- Humidity tolerance: up to 95% non-condensing
- Transducer power supply: -24 Vdc
- Shaft power supply: -24 Vdc
- Strong resistance to electromagnetic interference
Installation Guidelines
- Mounts directly into compatible 3500 racks.
- Supports standard Bently Nevada wiring practices.
- Channel labeling simplifies field installation.
- No special tools required for mounting.
Commissioning & Maintenance
- Fast setup using predefined configuration options.
- Minimal calibration required after installation.
- Front-access design simplifies inspection.
- Supports long service intervals.
Compatibility Information
- Fully compatible with Bently Nevada 3500 systems.
- Works with epoxy-sealed velocity seismoprobes.
- Integrates with existing protection logic.
Certification & Compliance
- Agency approval: Not required.
- Intrinsic safety barriers: Not included.
- Designed for industrial protection standards.
Typical Applications
- Steam and gas turbines.
- Compressors and large motors.
- Pumps in critical process units.
- Power generation monitoring systems.
Diagnostic Capabilities
- Detects imbalance and misalignment.
- Identifies early bearing wear.
- Supports trend-based maintenance decisions.
Package Contents
- One 3300/55 dual velocity monitor module.
- Factory inspection and test confirmation.
- Protective industrial packaging.
Warranty & Logistics
- Standard warranty: 12 months.
- Shipping methods: FedEx, UPS, DHL.
- Global delivery with secure packaging.
FAQ
- What is the main function of this module?
- It monitors velocity vibration for machinery protection.
- Is this module suitable for continuous operation?
- Yes. It is designed for 24/7 industrial environments.
- How do I choose the correct velocity range?
- Select based on machine speed and vibration limits.
- Can this module reduce unexpected downtime?
- Yes. Early fault detection improves maintenance planning.
- Is field replacement easy?
- Yes. The module supports quick rack replacement.
