Description
Product Introduction
- Brand: Bently Nevada
- Model: 3300/61-04-01-01-00-00-00
- Series: 3300 Series
- Type: XY Dual Vector Monitor Module
- Designed for precise shaft vibration vector monitoring.
- Tracks both amplitude and phase in two directions.
- Ideal for critical rotating machinery protection.
Core Performance Highlights
- Full Scale Range: 0 to 15 mils PP
- Scale Factor: 200 mV per mil
- Frequency Band: 0.1 Hz to 10 kHz
- Dynamic Range: Greater than 100 dB
- High signal clarity under heavy electrical noise.
- Stable output for long-term trending.
Electrical Characteristics
- Output Signal: 4 to 20 mA
- Input Voltage: 18 to 30 VDC
- Power Consumption: ≤ 50 mA
- Isolation: 1500 VDC
- Built-in signal conditioning improves accuracy.
Mechanical & Environmental Data
- Dimensions: 6.5 × 5.5 × 1.5 inches
- Weight: 0.54 kg
- Operating Temp: -40°C to +85°C
- Storage Temp: -40°C to +85°C
- Resists vibration and harsh plant conditions.
Installation & Connectivity
- Supports DIN rail and panel mounting.
- 15-pin D-sub connector simplifies wiring.
- Fast replacement reduces downtime.
Compatibility & Integration
- Works with proximity probe systems.
- Integrates into Bently Nevada 3300 racks.
- Direct interface with PLC and DCS systems.
Certifications
- CE compliant.
- UL certified.
- CSA approved.
Typical Applications
- Steam and gas turbines.
- Compressors and generators.
- High-speed motors and pumps.
- Balance and alignment diagnostics.
Package & Warranty
- 1 × XY Dual Vector Monitor Module.
- Industrial-grade protective packaging.
- Warranty: 12 months.
Shipping Methods
- FedEx express delivery.
- UPS international shipping.
- DHL worldwide service.
FAQ
- What is the key benefit of XY vector monitoring?
- It shows vibration direction and phase, not just level.
- Is this module suitable for high-speed machines?
- Yes. The wide frequency range supports fast rotation.
- What is a common setup tip from field use?
- Match probe gap and scale factor before startup.
- How do I choose between vector and amplitude modules?
- Use vector models when phase data matters.
- Can this module reduce false alarms?
- Yes. Vector analysis improves fault discrimination.
